Slate major components
Item Component Spare part number
(1) 11.6-in, TouchScreen display panel assembly:
FHD, BV, (1920×1080), IPS, 50% CG, typical brightness 400 nits, eDP 1.3, ultra-slim
with digitizer
793736-001
FHD, BV, (1920×1080), IPS, 50% CG, typical brightness 400 nits, eDP 1.3, ultra-slim
without digitizer
804352-001
HD, BV, (1366×768), IPS, 50% CG, typical brightness 400 nits, eDP 1.2, ultra-slim
with digitizer
793737-001
HD, BV, (1366×768), IPS, 50% CG, typical brightness 400 nits, eDP 1.2, ultra-slim
without digitizer
804351-001
Speaker grille (not illustrated; 2 pieces, includes double-sided adhesive) 793734-001
(2) RTC battery (includes cable and double-sided adhesive) 793723-001
20 Chapter 3 Illustrated parts catalog
