Item Component Description
Windows 8: See your power options. From the Start screen,
type power, select Settings, and then select Power Options.
Windows 7: See your power options. Select Start > Control
Panel > System and Settings > Power Options.
Linux:
1. Select Computer > Control Center.
2. In the left pane, click System, and then click Power
Management in the right pane.
(3) Micro SD memory card reader Reads optional memory cards that store, manage, share, or
access information.
To insert a card:
Hold the card label-side up, with connectors facing the slot,
insert the card into the slot, and then push in on the card until
it is firmly seated.
To remove a card:
Press in on the card it until it pops out.
(4) SIM Card slot (select models only) A slot for a SIM card.
(5) SIM/SD card release access A pinhole for use in ejecting the door covering the SIM and SD
card slots.
(6) USB 3.0 charging (powered) port Connects an optional USB device, such as a keyboard, mouse,
external drive, printer, scanner or USB hub. Standard USB
ports will not charge all USB devices or will charge using a
low current. Some USB devices require power and require you
to use a powered port.
NOTE: USB charging ports can also charge select models of
cell phones and MP3 players, even when the slate is off.
(7) Dual-Mode DisplayPort Connects an optional digital display device, such as a high-
performance monitor or projector.
(8) AC adapter/battery light
●
White: The slate is connected to external power and
the battery is charged from 90 to 99 percent.
●
Amber: The slate is connected to external power and
the battery is charged from 0 to 90 percent.
●
Blinking amber: A battery that is the only available
power source has reached a low battery level. When
the battery reaches a critical battery level, the battery
light begins blinking rapidly.
●
Off: The battery is fully charged.
(9) Power connector Connects an AC adapter.
*The antennas are not visible on the outside of the computer. For optimal transmission, keep the areas immediately around the
antennas free from obstructions.
For wireless regulatory notices, see the section of the Regulatory, Safety, and Environmental Notices that applies to your country or
region.
To access this guide:
Windows 10:
Select the Start button, select All apps, select HP Help and Support, and then select HP Documentation.
Right side 17
