HP ELITE x2 1012 G1 Maintenance And Service Guide

Item Component Spare part number
MU736 HS3110 HSPA+ w/GPS M.s 822828-001
WWAN antenna 844870-001
(5) Rear webcam 844883-001
(6) WLAN module
WIGIG Module W/Bracket W/Cable 844884-001
11ac 2x2 INT 8260NGW SnfP2 806721-001
11ac 2x2 INT 8260NGW SnfP2NV 806722-001
INT 802.11AC 18260+BT4 2x2 810814-005
WLAN antenna 844869-001
(7) Front webcam 844882-001
(8) Microphone board 844878-001
(9) Solid-state drive
128 GB SATA-3 TLC 844862-001
180 GB SATA-3 TLC 844863-001
180 GB SATA-3 self-encrypting drive OPAL2 844864-001
256 GB SATA-3 TLC 844865-001
256 GB SATA-3 self-encrypting drive OPAL2 844866-001
256 GB PCIe-3x4 NVMe 844868-001
512 GB SATA-3 TLC 844867-001
(10) USB Type-C bracket (included with system board. See System board on page 50.)
(11) Button board (includes cable)
For products with WWAN capability 844876-001
For products without WWAN capability 848827-001
(12) System board
UMA graphics M3-6Y30 4GBx2 1012 G1 with Windows operating system 844858-601
UMA graphics M3-6Y30 4GB fWWANx2 1012 G1 with Windows operating system and
WWAN capability
845470-601
UMA graphics M5-6Y54 4GBx2 1012 G1 with Windows operating system 845483-601
UMA graphics M5-6Y54 4GBx2 1012 G1 with Windows operating system and WWAN
capability
845484-601
UMA graphics M5-6Y54 8GBx2 1012 G1 with Windows operating system 845485-601
UMA graphics M5-6Y54 8GBx2 1012 G1 with Windows operating system 845486-601
UMA graphics M5-6Y57 4GB fWWANx2 1012 G1 with Windows operating system and
WWAN capability
845471-601
UMA graphics M5-6Y57 8GBx2 1012 G1 with Windows operating system 845472-601
20 Chapter 3 Illustrated parts catalog

HP ELITE x2 1012 G1 Specifications

General

Bus type	OPI
Stepping	D1
Tjunction	100 °C
Processor code	SR2EN
Processor cache	4 MB
Processor cores	2
Processor family	Intel® Core™ m3
Processor series	Intel Core m3-6Y series
Processor socket	BGA 1515
Processor threads	4
Processor codename	Skylake
Processor frequency	0.9 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	20 X 16.5 mm
Conflict-Free processor	Yes
PCI Express slots version	3.0
Processor boost frequency	2.2 GHz
Processor operating modes	32-bit, 64-bit
ECC supported by processor	No
Graphics & IMC lithography	14 nm
PCI Express configurations	1x2+2x1, 2x2, 1x4, 4x1
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Thermal Design Power (TDP)	4.5 W
Maximum number of PCI Express lanes	10
Device type	Tablet PC
Form factor	Slate
Product color	Silver
Internal memory	4 GB
Memory clock speed	1866 MHz
Internal memory type	LPDDR3-SDRAM
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash)
Internal storage capacity	180 GB
Display diagonal	12 \
Touch technology	Multi-touch
Display resolution	1920 x 1280 pixels
Graphics card	HD Graphics 515
On-board graphics card ID	0x191E
On-board graphics card model	Intel® HD Graphics 515
Maximum on-board graphics card memory	1.74 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card dynamic frequency (max)	850 MHz
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
Country of origin	China
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Battery capacity	2800 mAh
Battery life (max)	10 h
AC adapter power	45 W
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Sustainability certificates	ENERGY STAR
Platform	Windows
Operating system architecture	64-bit
Processor ARK ID	88198
Intel Secure Key Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00

Weight and Dimensions

Depth	213.5 mm
Width	300 mm
Height	8.05 mm
Weight	820 g
