Display panel
Description Spare part number
Panel 844861-001
Display Cable Kit 844872-001
IMPORTANT: Make special note of each screw and screw lock size and location during removal
and replacement.
Before removing the display panel, follow these steps:
1. Turn o the computer. If you are unsure whether the computer is o or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the following components:
a. Keyboard (select products only) (see Keyboard (select products only) on page 29)
b. Back cover (see Back cover on page 30)
Remove the display panel:
1. Use a suction tool to loosen all 4 corners of the display panel (1), and then lift the display panel (2) to
remove it.
Component replacement procedures 31
