Not all configuration components are available in all regions/countries.
c04895999 — DA – 15477 — Worldwide — Version 16 – March 22, 2017
Intel® Tri Band Wireless-AC 18260 802.11a/b/g/n/ac (2x2) and Bluetooth® 4.2 + WiGig Combo*
Combo Module, M.2 3030-S3-A
30.00±0.15mm by 30.00±0.15mm by 2.38mm max.
Wi-Fi certified MAC and Physical Layer
WiFi Alliance/WiGig Alliance Protocol Adaption Layers (PALs) (Not yet
ratified)
Wireless Display Extension (WDE)
Wireless Serial Extension (WSE)
Note: IP protocol is not supported
802.11ad
57 – 66 GHz
Note: There are 4 bands (1, 2, 3, 4) but only 2 (bands 2 and 3) are
supported in most of the countries on the planet. HP will support only
bands 2 and 3, 59-64 GHz
Note: Not all countries allow unlicensed operation at these
frequencies
Antenna Structure
(Remote Front End Module,
R-FEM)
Active, Beam Steering Array of 10 x 2 Elements, 8 x 2 Active Elements
Azimuth 8 active elements
Elevation 2 active elements
Vertical tilt of 20 to 30 degrees off of broadside
Horizontal beam steering ±65°, -6dB from peak gain
Vertical beam steering +80° -50°, -6dB from peak gain
Azimuth beam width ~20°, -6dB from peak gain
Elevation beam width ~80°, -6dB from peak gain
Omni (no beam forming) beam width ~110°, -6dB from peak gain
Vertical Polarization
Device side supports one R-FEM
Dock side supports one or two R-FEMs
MCS Rate, Mbit/s Modulation
0 27.5 π/2-BPSK
1 385.0 π/2-BPSK
2 770.0 π/2-BPSK
3 962.5 π/2-BPSK
4 1155.0 π/2-BPSK
5 1251.25 π/2-BPSK
6 1540.0 π/2-QPSK
7 1925.0 π/2-QPSK
8 2310.0 π/2-QPSK
9 2502.5 π/2-QPSK
10 3080.0 π/-16QAM
11 3850.0 π/-16QAM
12 4620.0 π/-16QAM
