HP ELITE x2 1012 G1 Quickspecs

QuickSpecs
HP Elite x2 1012 G1
Technical Specifications
Not all configuration components are available in all regions/countries.
c04895999 — DA – 15477 — Worldwide — Version 16 – March 22, 2017
Page 21
Wireless Display Extension (WDE)
WGA WDE support
AV PAL (WDE) as defined by WiGig alliance
AVC/MPEG support -
encoder
WDE supports generation of MPEG-PS /
MPEG-PES packets as described in the
WDE standard
WDE supports AVC (H264) encoder, intra
only, 4:4:4 Chroma subsampling.
Different visually lossless and lossy
scenarios are supported by configuration
AVC/MPEG support –
decoder
H.264 CAVLC 4:4:4 I-only sub sampling is
supported
Type of Interface
Client device side
 DP (Display port) v1.2a – HBR (1, 2, 4
lanes)
Dock device side
 DP v1.2 – HBR (1, 2, 4 lanes)
 HDMI v1.4a (through external Hub or
cable adapter)
 DP++ compatible
Note: DP v1.2 is backward compatible
with DP v1.1a
DP Resolution and Frame
Rate Support
HDMI Resolution and
Frame Rate Support
DP will support the following resolutions
640x480, 1280x720, 1920x1080,
1920x1200, 2560x1440, 2560x1600
and frame rates –
24, 25, 30, 50 and 60 Hz
All resolutions are in progressive mode
(no interlaced supported)
Specifically, the following resolutions and
frame rats will be supported
 640x480p60
 1280x720p60
 1920x1080p60
 1920x1200p60
 2560x1440p60
 2560x1600p60
Note: resolution and refresh rate may
change in situations where there is a bad
link or strict limits on TDP
HDMI supports the following resolution
and frame rates –
 640x480p60
 1280x720p60
 1920x1080p60
 1920x1200p60
 2560x1440p60
 2560x1600p60
Note: resolution and refresh rate may
change in situations where there is a bad
link or strict limits on TDP
Color space support
YCbCr and RGB

HP ELITE x2 1012 G1 Specifications

General

Bus type	OPI
Stepping	D1
Tjunction	100 °C
Processor code	SR2EN
Processor cache	4 MB
Processor cores	2
Processor family	Intel® Core™ m3
Processor series	Intel Core m3-6Y series
Processor socket	BGA 1515
Processor threads	4
Processor codename	Skylake
Processor frequency	0.9 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	20 X 16.5 mm
Conflict-Free processor	Yes
PCI Express slots version	3.0
Processor boost frequency	2.2 GHz
Processor operating modes	32-bit, 64-bit
ECC supported by processor	No
Graphics & IMC lithography	14 nm
PCI Express configurations	1x2+2x1, 2x2, 1x4, 4x1
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Thermal Design Power (TDP)	4.5 W
Maximum number of PCI Express lanes	10
Device type	Tablet PC
Form factor	Slate
Product color	Silver
Internal memory	4 GB
Memory clock speed	1866 MHz
Internal memory type	LPDDR3-SDRAM
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash)
Internal storage capacity	180 GB
Display diagonal	12 \
Touch technology	Multi-touch
Display resolution	1920 x 1280 pixels
Graphics card	HD Graphics 515
On-board graphics card ID	0x191E
On-board graphics card model	Intel® HD Graphics 515
Maximum on-board graphics card memory	1.74 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card dynamic frequency (max)	850 MHz
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
Country of origin	China
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Battery capacity	2800 mAh
Battery life (max)	10 h
AC adapter power	45 W
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Sustainability certificates	ENERGY STAR
Platform	Windows
Operating system architecture	64-bit
Processor ARK ID	88198
Intel Secure Key Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00

Weight and Dimensions

Depth	213.5 mm
Width	300 mm
Height	8.05 mm
Weight	820 g
