HP ELITE x2 1012 G1 Quickspecs

QuickSpecs
HP Elite x2 1012 G1
Technical Specifications
Not all configuration components are available in all regions/countries.
c04895999 — DA – 15477 — Worldwide — Version 16 – March 22, 2017
Page 6
GRAPHICS
Intel® HD Graphics 515
DISPLAY
Internal
Touch screen
12.0" diagonal BrightView LED-backlit WUXGA UWVA eDP 1.3 Ultra-slim (1920 x 1280 – Full HD*) Touch screen Chemically-
strengthened Corning® Gorilla® Glass 4 top cover directly bonded to display
Refresh Rate
60 Hz
Brightness
340 nits (typical)
Pixel Resolution
Format
1920 x 1280 (WUXGA+)
Configuration
RGB Stripe
Interface
eDP 1.3
LCD Mode
IPS/FFS/VA
PPI
192 ppi
Viewing Angle
UWVA 85/85/85/85 (Left/Right/Down/Up)
External
24-bit + 8 bit alpha channel (standard)
Up to 30-bit per pixel color depth (Wide Color Gamut)
* HD content required to view HD images.
NOTE: Resolutions are dependent upon monitor capability, and resolution and color depth settings.
STORAGE AND DRIVES
Internal Storage*
Supports M.2 SSD SS 2280
128 GB SATA III Solid State Drive
180 GB SATA III Solid State Drive
180 GB SATA III SED OPAL2 Solid State Drive
256 GB SATA III Solid State Drive
256 GB SATA III Solid State Drive PCle NVMe
256 GB SATA III SED OPAL2 Solid State Drive
512 GB SATA III Solid State Drive
* For SSD's, GB=1 billion bytes. TB=1 trillion bytes. Actual formatted capacity is less. Up to 16 GB (for Windows 7) and up to 30
GB (for Windows 8 and 10) of system disk is reserved for system recovery software.
Expansion Storage
Micro SD Media Reader Slot - Supports microSD, microSDHC, microSDXC, supporting expansion up to 200GB
MEMORY
LPDDR3-1866 (Transfer rates up to 1866 MT/s)
Supports Dual Channel Memory
Soldered Down

HP ELITE x2 1012 G1 Specifications

General

Bus type	OPI
Stepping	D1
Tjunction	100 °C
Processor code	SR2EN
Processor cache	4 MB
Processor cores	2
Processor family	Intel® Core™ m3
Processor series	Intel Core m3-6Y series
Processor socket	BGA 1515
Processor threads	4
Processor codename	Skylake
Processor frequency	0.9 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	20 X 16.5 mm
Conflict-Free processor	Yes
PCI Express slots version	3.0
Processor boost frequency	2.2 GHz
Processor operating modes	32-bit, 64-bit
ECC supported by processor	No
Graphics & IMC lithography	14 nm
PCI Express configurations	1x2+2x1, 2x2, 1x4, 4x1
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Thermal Design Power (TDP)	4.5 W
Maximum number of PCI Express lanes	10
Device type	Tablet PC
Form factor	Slate
Product color	Silver
Internal memory	4 GB
Memory clock speed	1866 MHz
Internal memory type	LPDDR3-SDRAM
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash)
Internal storage capacity	180 GB
Display diagonal	12 \
Touch technology	Multi-touch
Display resolution	1920 x 1280 pixels
Graphics card	HD Graphics 515
On-board graphics card ID	0x191E
On-board graphics card model	Intel® HD Graphics 515
Maximum on-board graphics card memory	1.74 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card dynamic frequency (max)	850 MHz
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
Country of origin	China
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Battery capacity	2800 mAh
Battery life (max)	10 h
AC adapter power	45 W
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Sustainability certificates	ENERGY STAR
Platform	Windows
Operating system architecture	64-bit
Processor ARK ID	88198
Intel Secure Key Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00

Weight and Dimensions

Depth	213.5 mm
Width	300 mm
Height	8.05 mm
Weight	820 g
