HP ELITE x2 1012 G1 Quickspecs

QuickSpecs
HP Elite x2 1012 G1
Technical Specifications
Not all configuration components are available in all regions/countries.
c04895999 — DA – 15477 — Worldwide — Version 16 – March 22, 2017
Page 7
Standard
4 GB Total System Memory
8 GB Total System Memory
Maximum
Up to 8 GB
NETWORKING/COMMUNICATIONS
Wireless
Support for a broad range of secure, integrated wireless LAN and wireless WAN options featuring support for the latest
industry standards. Broadband Wireless (WWAN) requires a Windows operating system and is available in select countries as
a standard, factory configurable feature only. Integrated Bluetooth is also available (factory configurable only) and is
supported via combo card.
Wireless WAN (WWAN)*
HP hs3110 HSPA+ Intel® Mobile Broadband*
HP lt4120 Qualcomm® Snapdragon™ X5 LTE Mobile Broadband*
HP lt4225 LTE/EV-DO Gobi™ 4G Mobile Broadband*
HP lt4226 LTE/HSPA+ Gobi™ 4G Mobile Broadband*
Wireless LAN (WLAN)**
Intel® Dual Band Wireless-AC 8260 802.11a/b/g/n/ac (2x2) WiFi and Bluetooth® 4.2 Combo;
Intel® Tri Band Wireless-AC 18260 802.11a/b/g/n/ac (2x2) and Bluetooth® 4.2 + WiGig Combo;
* WWAN is an optional feature and requires factory configuration. WWAN connection requires wireless data service contract,
network support, and is not available in all areas. Contact service provider to determine the coverage area and availability.
Connection speeds will vary due to location, environment, network conditions, and other factors. 4G LTE not available on all
products, in all regions
**Wireless access point and Internet service is required and is not included. Availability of public wireless access points
limited.
***The WiGig-compatible notebook or tablet must be positioned within 1.2 m (4 ft) and without obstruction in the line of sight
of the wireless dock. HP Advanced Wireless Docking is compatible with the HP Elite x2 1012 G1 with an optional installed
Intel Tri Band Wireless AC with WiGig Combo card available at the time of purchase.
AUDIO/MULTIMEDIA
Audio
Audio by Bang & Olufsen
Dual speakers (top facing)
Dual microphone array with echo cancellation, noise suppression
Headphone line-out and microphone-in (combo)
HP Advanced Noise Reduction Software
Camera – Front
Integrated 2 MP (1080p)
 1080p format for video
 2 MP for still capture
 Supports videoconferencing* and still image capture
 High quality fixed focus lens
 Video capture at various resolutions up to 1920x1080 resolution (1080p) and up to 30 fps
 M-JPEG compression supports higher frame rates for video capture and videoconferencing*

HP ELITE x2 1012 G1 Specifications

General

Bus type	OPI
Stepping	D1
Tjunction	100 °C
Processor code	SR2EN
Processor cache	4 MB
Processor cores	2
Processor family	Intel® Core™ m3
Processor series	Intel Core m3-6Y series
Processor socket	BGA 1515
Processor threads	4
Processor codename	Skylake
Processor frequency	0.9 GHz
Processor cache type	Smart Cache
Processor manufacturer	Intel
Processor package size	20 X 16.5 mm
Conflict-Free processor	Yes
PCI Express slots version	3.0
Processor boost frequency	2.2 GHz
Processor operating modes	32-bit, 64-bit
ECC supported by processor	No
Graphics & IMC lithography	14 nm
PCI Express configurations	1x2+2x1, 2x2, 1x4, 4x1
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Thermal Design Power (TDP)	4.5 W
Maximum number of PCI Express lanes	10
Device type	Tablet PC
Form factor	Slate
Product color	Silver
Internal memory	4 GB
Memory clock speed	1866 MHz
Internal memory type	LPDDR3-SDRAM
Storage media	SSD
Compatible memory cards	MicroSD (TransFlash)
Internal storage capacity	180 GB
Display diagonal	12 \
Touch technology	Multi-touch
Display resolution	1920 x 1280 pixels
Graphics card	HD Graphics 515
On-board graphics card ID	0x191E
On-board graphics card model	Intel® HD Graphics 515
Maximum on-board graphics card memory	1.74 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card dynamic frequency (max)	850 MHz
Rear camera type	Single camera
Rear camera resolution (numeric)	5 MP
Front camera resolution (numeric)	2 MP
Country of origin	China
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Battery capacity	2800 mAh
Battery life (max)	10 h
AC adapter power	45 W
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Sustainability certificates	ENERGY STAR
Platform	Windows
Operating system architecture	64-bit
Processor ARK ID	88198
Intel Secure Key Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00

Weight and Dimensions

Depth	213.5 mm
Width	300 mm
Height	8.05 mm
Weight	820 g
