HP EliteBook 820 G3 User Manual

Category Description
●
500 GB, 7200 rpm, 7.0 mm, self-encrypting (Opal 2)
●
500 GB, 7200 rpm, 7.0 mm
●
500 GB, 7.0 mm, hybrid, 8 GB cach
SSDs:
●
M.2 (2280) 512 GB SATA-3 TLC
●
M.2 (2280) 256 GB PCIe-3×4 SS NVMe
●
M.2 (2280) 256 GB SATA-3 self-encrypting (Opal 2) MLC
●
M.2 (2280) 256 GB SATA-3 TLC
●
M.2 (2280) 240 GB SATA-3 MLC DS
●
M.2 (2280) 180 GB SATA-3 self-encrypting (Opal 2) MLC
●
M.2 (2280) 180 GB SATA-3 MLC
●
M.2 (2280) 128 GB SATA-3 TLC
Audio and video Supports:
DTS Studio Sound
Conexant smart amplier and ambient noise suppression
Dual-array microphone
Dual speakers
Webcamera (720p)
●
Intel WGI219V 10/100/1000 Ethernet, non-vPro, for use with computer models with i7-6500U,
i5-6200U, or i3-6100U processors
●
Intel WGI219LM 10/100/1000 Ethernet, iAMT, for use with computer models with i7-6600U or i5-6300U
processors
S3/S4/S5 Wake-on-LAN
Wireless WLAN
Integrated wireless local area network (WLAN) options by way of wireless module
Two WLAN antennas built into display assembly
Integrated wireless personal area network (PAN) supported by Bluetooth
®
4.0 or Bluetooth 4.2 combo card
Compatible with Miracast-certied devices
Support for the following WWAN formats:
●
Intel Dual Band Wireless-AC 8260NGW 802.11a/b/g/n+ac 2x2 Wi-Fi + BT 4.2 combo adapter (i7-6600U,
i5-6300U)
●
Intel Dual Band Wireless-AC 8260NGW 802.11a/b/g/n+ac non–vPro 2x2 Wi-Fi + BT 4.2 combo adapter
(i7-6500U, i5-6200U, i3-6100U)
●
Intel Dual Band Wireless-AC 3165 802.11a/b/g/n+ac 1x1 Wi-Fi + BT 4.0 combo adapter (i7-6500U,
i5-6200U, i3-6100U)
Supports no WLAN option
NFC
Supports the following NFC formats:
Integrated NFC Galapagos NXP NPC100 12C NCI 10 mm x 25 mm module
2 Chapter 1 Product description

HP EliteBook 820 G3 Specifications

General

Form factor	Clamshell
Product type	Ultrabook
Product color	Silver
Country of origin	China
Bus type	QPI
Stepping	D1
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-6200U
System bus rate	4 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-6200 series
Processor socket	LGA 1356 (Socket B2)
Processor threads	4
Processor codename	Skylake
Configurable TDP-up	25 W
Processor frequency	2.3 GHz
Processor cache type	Smart Cache
Configurable TDP-down	7.5 W
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	2.8 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x4, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2.4 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	12
Motherboard chipset	-
Pointing device	Touchpad
Spill-resistant keyboard	Yes
Recovery operating system	Windows 10 Pro
Operating system installed	Windows 7 Professional
Processor code	SR2EY
Processor ARK ID	88193
Processor package size	42 X 24 mm
CPU configuration (max)	1
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Intel Smart Response Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	16 GB
Memory layout (slots x size)	1 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	SATA
Storage media	SSD
Total storage capacity	256 GB
Compatible memory cards	SD, SDHC, SDXC
Display surface	Matt
Display diagonal	12.5 \
Native aspect ratio	16:9
On-board graphics card ID	1916
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 520
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1000 MHz
Battery capacity	44 Wh
Battery life (max)	- h
Number of battery cells	3
AC adapter power	45 W
Intel segment tagging	Enterprise
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Sustainability certificates	ENERGY STAR
HP segment	Business
HP Software provided	HP BIOSphere with HP Sure Start, HP Client Security, HP Image Assistant, HP SoftPaq Download Manager, HP Connection Manager, HP Noise Reduction Software
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	218.9 mm
Width	311 mm
Height	18.9 mm
Weight	1260 g
