HP EliteBook 820 G3 User Manual

1 Product description
Category Description
Product Name HP EliteBook 820 G3 Notebook PC
Processors Processors are attached to the system board.
Sixth-generation Intel
®
Core™ processors:
●
Intel Core™ i7-6600U
●
Intel Core i7-6500U
●
Intel Core i5-6300U
●
Intel Core i5-6200U
●
Intel Core i3-6100U
Chipset Integrated with processor
Intel Skylake Premium, for use with 6th generation Intel Core processors
Intel UMA graphics (with shared video memory)
Up to three independent displays supported with docking solution
●
Intel HD Graphics 520
Panel 12.5 in (31.75 cm), high-denition (HD), Slim eDP (1366×768), SVA AG, typical brightness: 220 cd/m2 (nits)
with and without webcam
12.5 in (31.75 cm),full high-denition (FHD), UltraSlim eDP (1920x1080), UWVA AG, typical brightness: 300
cd/m2 (nits) with and without webcam
12.5 in (31.75 cm),full high-denition (FHD), UltraSlim eDP (1920x1080) UWVA AG, typical brightness: 300
cd/m2 (nits) with touch and webcam
Memory Two SODIMM customer-accessible/upgradable memory module slots
Supports up to 16 GB of system RAM
DDR4 PC4-17000 (2133 MHz) dual channel support
Supports the following congurations:
●
16384 MB (8192 MB×2; not supported on computer models with a Windows
®
7 32-bit operating system)
●
12288 (8192 MB + 4096 MB; not supported on computer models with a Windows 7 32-bit operating
system)
●
8192 MB (8192 MB×1 or 4096 MB×2; not supported on computer models with a Windows 7 32-bit
operating system)
●
4096 MB (4096 MB×1)
Hard drive HDDs:
Supports 6.35 cm (2.5 in) hard drives in 7.0 mm (.28 in) thicknesses (all hard drives use the same bracket)
Serial ATA
●
1 TB, 5400 rpm, 7.0 mm
●
500 GB, 7200 rpm, 7.0 mm, self-encrypting (FIPS-140-2; Opal 2)
1

HP EliteBook 820 G3 Specifications

General

Form factor	Clamshell
Product type	Ultrabook
Product color	Silver
Country of origin	China
Bus type	QPI
Stepping	D1
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-6200U
System bus rate	4 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-6200 series
Processor socket	LGA 1356 (Socket B2)
Processor threads	4
Processor codename	Skylake
Configurable TDP-up	25 W
Processor frequency	2.3 GHz
Processor cache type	Smart Cache
Configurable TDP-down	7.5 W
Processor lithography	14 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	2.8 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x4, 4x1
Thermal Design Power (TDP)	15 W
Configurable TDP-up frequency	2.4 GHz
Configurable TDP-down frequency	0.8 GHz
Maximum number of PCI Express lanes	12
Motherboard chipset	-
Pointing device	Touchpad
Spill-resistant keyboard	Yes
Recovery operating system	Windows 10 Pro
Operating system installed	Windows 7 Professional
Processor code	SR2EY
Processor ARK ID	88193
Processor package size	42 X 24 mm
CPU configuration (max)	1
Supported instruction sets	SSE4.1, SSE4.2, AVX 2.0
Intel Smart Response Technology version	1.00
Intel Stable Image Platform Program (SIPP) version	0.00
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory clock speed	2133 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	16 GB
Memory layout (slots x size)	1 x 8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	SATA
Storage media	SSD
Total storage capacity	256 GB
Compatible memory cards	SD, SDHC, SDXC
Display surface	Matt
Display diagonal	12.5 \
Native aspect ratio	16:9
On-board graphics card ID	1916
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 520
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.74 GB
On-board graphics card OpenGL version	4.4
On-board graphics card base frequency	300 MHz
On-board graphics card DirectX version	12.0
On-board graphics card dynamic frequency (max)	1000 MHz
Battery capacity	44 Wh
Battery life (max)	- h
Number of battery cells	3
AC adapter power	45 W
Intel segment tagging	Enterprise
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	0
Sustainability certificates	ENERGY STAR
HP segment	Business
HP Software provided	HP BIOSphere with HP Sure Start, HP Client Security, HP Image Assistant, HP SoftPaq Download Manager, HP Connection Manager, HP Noise Reduction Software
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	218.9 mm
Width	311 mm
Height	18.9 mm
Weight	1260 g
