2. Remove the drive (2) by pulling it away from the connector.
NOTE: mSATA drives are designed with notches to prevent incorrect insertion.
Reverse this procedure to reassemble and install the mSATA drive.
NOTE: Only a hard drive or an SSD can be installed. To install an SSD, be sure that the standee is in place
across from the connector and not stored beside the hard drive slot.
Component replacement procedures 39
