HP EliteBook 840 G2 Notebook PC Service Manual

Item Component Spare part number
(13) Hard drive (does not include hard drive bracket or screws)
NOTE: The hard drive bracket and screws are included in the Hard Drive Hardware Kit, spare part number 730793-001.
1-TB, 7200-rpm, SATA, 9.5-mm hard drive for use on all computer models 766644-001
500-GB, 7200-rpm, SATA, 7.0-mm hard drive for use on all computer models 703268-001
500-GB, 7200-rpm, SED, 7.0-mm hard drive for use on all computer models 703267-001
500-GB, 5400-rpm, FIPS, 7.0-mm hard drive for use on all computer models 730946-001
(14) Fan (includes cable and captive screws) 730792-001
(15) Heat sink (includes replacement thermal material):
For use only on computer models equipped with a graphics subsystem with discrete
memory
803017-001
For use only on computer models equipped with a graphics subsystem with UMA memory 803016-001
(16) Memory modules (PC3L, 12800, 1600-MHz):
8-GB memory module 693374-001
4-GB memory module 691740-001
(17) System board (includes replacement thermal material):
Equipped with an Intel Core i7-5600U 2.60-GHz (SC turbo up to 3.20-GHz) processor (4.0-
MB L3 cache, dual core, 15-W), AMD Radeon R7 M260X graphics subsystem with discrete
memory, and the Windows 8 Professional operating system for use only on HP EliteBook
840 G2 Notebook PC computer models
799543-601
Equipped with an Intel Core i7-5600U 2.60-GHz (SC turbo up to 3.20-GHz) processor (4.0-
MB L3 cache, dual core, 15-W), AMD Radeon R7 M260X graphics subsystem with discrete
memory, and the Windows 8 Standard operating system for use only on HP EliteBook 840
G2 Notebook PC computer models
799543-501
Equipped with an Intel Core i7-5600U 2.60-GHz (SC turbo up to 3.20-GHz) processor (4.0-
MB L3 cache, dual core, 15-W), AMD Radeon R7 M260X graphics subsystem with discrete
memory, and a non-Windows 8 operating system for use only on HP EliteBook 840 G2
Notebook PC computer models
799543-001
Equipped with an Intel Core i7-5600U 2.60-GHz (SC turbo up to 3.20-GHz) processor (4.0-
MB L3 cache, dual core, 15-W), AMD FirePro M4170 128-bit (GDDR5) graphics subsystem
with discrete memory, and the Windows 8 Professional operating system for use only on
HP ZBook 14 G2 Mobile Workstation computer models
802792-601
Equipped with an Intel Core i7-5600U 2.60-GHz (SC turbo up to 3.20-GHz) processor (4.0-
MB L3 cache, dual core, 15-W), AMD FirePro M4170 128-bit (GDDR5) graphics subsystem
with discrete memory, and the Windows 8 Standard operating system for use only on
HP ZBook 14 G2 Mobile Workstation computer models
802792-501
Equipped with an Intel Core i7-5600U 2.60-GHz (SC turbo up to 3.20-GHz) processor (4.0-
MB L3 cache, dual core, 15-W), AMD FirePro M4170 128-bit (GDDR5) graphics subsystem
with discrete memory, and a non-Windows 8 operating system for use only on HP ZBook
14 G2 Mobile Workstation computer models
802792-001
Equipped with an Intel Core i7-5600U 2.60-GHz (SC turbo up to 3.20-GHz) processor (4.0-
MB L3 cache, dual core, 15-W), Intel HD Graphics 5500 graphics subsystem with UMA
memory, and the Windows 8 Professional operating system for use only on HP EliteBook
840 G2 Notebook PC computer models
799513-601
34 Chapter 3 Illustrated parts catalog ENWW
