Item Component Spare part number
(1) Display assembly, touch
Touch screen display assemblies are spared only as whole unit hinge-ups.
All privacy display assemblies including non-touch are spared as whole unit hinge-ups.
Non-touch display assemblies are spared at the subcomponent level only. For more non-
touch display assembly spare part information, see Display assembly subcomponents
on page 21.
Touch 910584-001
Privacy 922076-001
(2) Keyboard (see Keyboard on page 47)
For a list of keyboard country codes, see Keyboard on page 47.
Without a backlight 836307-xx1
With a backlight 836308-xx1
With a backlight, privacy 903008-xx1
For use in Japan; without a backlight 923272-291
For use in Japan; with a backlight 923273-291
(3) Top cover
Standard top cover 821173-001
Privacy 903979-001
(4) Power button board 914382-001
(5) Smart card reader board (includes cable) 914380-001
(6) NFC module (includes NFC cable, antenna cable, Mylar insulator, and foam) 821666-001
(7) Fingerprint reader assembly (includes cable) 849912-001
(8) TouchPad
Without NFC antenna 821171-001
Including NFC antenna 821172-001
(9) Speakers (includes cable) 821170-001
(10) System board (includes processor and replacement thermal material, see System board on page 62)
All system boards use the following part numbers:
xxxxxx-001: Non-Windows operating systems
xxxxxx-601: Windows operating system
Intel i7-7600U processor 917507-xx1
Intel i7-7500U processor 917504-xx1
Intel i5-7300U processor 917501-xx1
Intel i5-7200U processor 917503-xx1
Intel i3-7100U processor 917499-xx1
Computer major components 19
