HP EliteBook 8440P Quickspecs

Intel Centrino Advanced-
Intel Centrino Advanced-Intel Centrino Advanced-
Intel Centrino Advanced-
N 6200 (2x2)
N 6200 (2x2)N 6200 (2x2)
N 6200 (2x2)
Integrated support for 802.11a, b, g, and n *
2 transmit, 2 receive antennas
Up to 300 mbps data rate
Broadcom 4312G
Broadcom 4312GBroadcom 4312G
Broadcom 4312G
802.11b/g
802.11b/g802.11b/g
802.11b/g
WiFi Adapter
WiFi AdapterWiFi Adapter
WiFi Adapter
Integrated support for 802.11 b and g
Up to 54 mbps data rate
Broadcom 43224AGN
Broadcom 43224AGNBroadcom 43224AGN
Broadcom 43224AGN
802.11a/b/g/n
802.11a/b/g/n802.11a/b/g/n
802.11a/b/g/n
WiFi Adapter
WiFi AdapterWiFi Adapter
WiFi Adapter
Integrated support for 802.11 a, b, g and n
2 transmit, 2 receive antennas
Up to 300 mbps data rate
HP Integrated Module
HP Integrated ModuleHP Integrated Module
HP Integrated Module
with Bluetooth Wireless
with Bluetooth Wirelesswith Bluetooth Wireless
with Bluetooth Wireless
Technology
TechnologyTechnology
Technology
Bluetooth Specification v2.1 compliant
Works with a wide range of Bluetooth devices
* In countries where 802.11n is not allowed, this capability is not enabled (802.11a/b/g only).
Keyboard
KeyboardKeyboard
Keyboard The HP spill-resistant keyboard is designed using a thin layer of Mylar film under the keyboard and a
drain system that funnels fluid through a hole in the bottom of the notebook. This minimizes the risk of
damage to sensitive components underneath. The 101/102-key compatible keyboard features an
industry standard, full-pitch key layout with desktop keyboard features, such as the isolated inverted-T
cursor control keys, editing keys, both left and right control and alt keys, and 12 function keys. U.S. and
International key layouts are available. Includes an integrated numeric keypad, hotkeys for instant access
to power conservation, brightness, and other features. It has 19.05 x 19.05 mm key pitch (center-to-
center spacing) and 2.5 mm stroke.
Touch-sensitive controls
Touch-sensitive controlsTouch-sensitive controls
Touch-sensitive controls Touch-sensitive controls provide easy access to the following features: HP QuickLook 3, HP QuickWeb,
wireless on/off, volume mute, volume down, volume up, touchpad on/off
Dual Pointing devices
Dual Pointing devicesDual Pointing devices
Dual Pointing devices Touchpad with scroll zone, two pick buttons
Pointstick with two additional pointstick buttons
Expansion card slots
Expansion card slotsExpansion card slots
Expansion card slots ExpressCard/54 slot
ExpressCard/54 slotExpressCard/54 slot
ExpressCard/54 slot Supports ExpressCard/54
Integrated Smart Card
Integrated Smart CardIntegrated Smart Card
Integrated Smart Card
Reader
ReaderReader
Reader
Compatible with ISO 7816 compliant Smart Cards
PC/SC interface support
Secure Digital slot
Secure Digital slotSecure Digital slot
Secure Digital slot Supports SD (Secure Digital), MMC (MultiMedia Card)
QuickSpecs
HP EliteBook 8440p Notebook PC
HP EliteBook 8440p Notebook PCHP EliteBook 8440p Notebook PC
HP EliteBook 8440p Notebook PC
Standard Features
DA - 13520 Canada — Version 16 — September 29, 2011 Page 8

HP EliteBook 8440P Specifications

General

HDD speed	7200 RPM
HDD interface	SATA II
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	MMC, SD
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Bus type	DMI
Stepping	C2
Tjunction	105 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-620M
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-600 Mobile Series
Processor socket	BGA 1288
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.66 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
PCI Express slots version	2.0
Processor boost frequency	3.33 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	20
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® QM57 Express
Display diagonal	14 \
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
Discrete graphics card model	NVIDIA Quadro HD 6310
Maximum graphics card memory	- GB
On-board graphics card model	Intel® HD Graphics
Discrete graphics card memory	0.512 GB
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	766 MHz
Type	PC
Graphics card family	NVIDIA
Intel segment tagging	Enterprise
Audio system	HP Premier Sound
Bluetooth version	2.1+EDR
Networking features	Gigabit Ethernet
Mobile network generation	3G
Operating system installed	Windows 7 Professional
Number of battery cells	6
Charging port type	DC-in jack
Serial ports quantity	-
USB 2.0 ports quantity	3
CardBus PCMCIA slots quantity	0
Cable lock slot type	Kensington
Product color	Silver
Country of origin	China
Keyboard layout	QWERTY
Pointing device	Touchpad
Processor code	SLBPE
Processor ARK ID	43560
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1/4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	36 bit

Weight and Dimensions

Depth	236 mm
Width	336 mm
Weight	2120 g
Height (front)	31 mm
