HP EliteBook 8440P Quickspecs

Internal Storage
Internal StorageInternal Storage
Internal Storage Hard Drives
Hard DrivesHard Drives
Hard Drives 160/250/320/500 GB 7200 rpm SMART SATA II
320 GB 7200 rpm SMART SATA II Self Encrypting Drive
NOTE:
NOTE:NOTE:
NOTE: These hard drives are customer removable and will withstand multiple insertion/removal cycles.
Up to 10 GB is reserved for the system recovery software.
HP 3D DriveGuard
HP 3D DriveGuardHP 3D DriveGuard
HP 3D DriveGuard
(Windows only)
The hard drive is mounted directly to the notebook frame, reducing the
transmission of shock to the hard drive. Uses three-axis digital motion
detection with intelligent sensitivity to help protect the hard drive during
normal use from shock and vibration. The digital accelerometer temporarily
halts all data transfer and parks the hard drive when abrupt motion is
detected.
Solid State Drives
Solid State DrivesSolid State Drives
Solid State Drives 160 GB Solid State Drive
256 GB Solid State Drive
Upgrade Bay
Upgrade BayUpgrade Bay
Upgrade Bay Fixed 12.7 mm SATA
Fixed 12.7 mm SATAFixed 12.7 mm SATA
Fixed 12.7 mm SATA
optical drive
optical driveoptical drive
optical drive
Blu-ray R/RE DVD+/-RW SuperMulti DL Drive
Blu-ray ROM DVD+/-RW SuperMulti DL LightScribe Drive
DVD+/-RW SuperMulti DL LightScribe Drive
DVD-ROM Drive
Second hard drive
Second hard driveSecond hard drive
Second hard drive 500 GB 7200 rpm SMART SATA II Hard Drive
Weight saver
Weight saverWeight saver
Weight saver
Interfaces
InterfacesInterfaces
Interfaces ExpressCard/54 slot
ExpressCard/54 slotExpressCard/54 slot
ExpressCard/54 slot One
External monitor
External monitorExternal monitor
External monitor Two - (1) DisplayPort, (1) VGA
Smart Card Reader
Smart Card ReaderSmart Card Reader
Smart Card Reader One
1394a
1394a1394a
1394a One
Stereo microphone in
Stereo microphone inStereo microphone in
Stereo microphone in One
Stereo headphone/line
Stereo headphone/lineStereo headphone/line
Stereo headphone/line
out
outout
out
One
Power connector
Power connectorPower connector
Power connector One
RJ-11/modem
RJ-11/modemRJ-11/modem
RJ-11/modem One
RJ-45/Ethernet
RJ-45/EthernetRJ-45/Ethernet
RJ-45/Ethernet One
USB 2.0
USB 2.0USB 2.0
USB 2.0 Three
eSATA/USB 2.0 Combo
eSATA/USB 2.0 ComboeSATA/USB 2.0 Combo
eSATA/USB 2.0 Combo
port
portport
port
One
Docking connector
Docking connectorDocking connector
Docking connector One
Secondary battery
Secondary batterySecondary battery
Secondary battery
connector
connectorconnector
connector
One
QuickSpecs
HP EliteBook 8440p Notebook PC
HP EliteBook 8440p Notebook PCHP EliteBook 8440p Notebook PC
HP EliteBook 8440p Notebook PC
Standard Features
DA - 13520 Canada — Version 16 — September 29, 2011 Page 9

HP EliteBook 8440P Specifications

General

HDD speed	7200 RPM
HDD interface	SATA II
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	MMC, SD
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Bus type	DMI
Stepping	C2
Tjunction	105 °C
Processor cache	4 MB
Processor cores	2
Processor model	i7-620M
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-600 Mobile Series
Processor socket	BGA 1288
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.66 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
PCI Express slots version	2.0
Processor boost frequency	3.33 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	20
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® QM57 Express
Display diagonal	14 \
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
Discrete graphics card model	NVIDIA Quadro HD 6310
Maximum graphics card memory	- GB
On-board graphics card model	Intel® HD Graphics
Discrete graphics card memory	0.512 GB
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	766 MHz
Type	PC
Graphics card family	NVIDIA
Intel segment tagging	Enterprise
Audio system	HP Premier Sound
Bluetooth version	2.1+EDR
Networking features	Gigabit Ethernet
Mobile network generation	3G
Operating system installed	Windows 7 Professional
Number of battery cells	6
Charging port type	DC-in jack
Serial ports quantity	-
USB 2.0 ports quantity	3
CardBus PCMCIA slots quantity	0
Cable lock slot type	Kensington
Product color	Silver
Country of origin	China
Keyboard layout	QWERTY
Pointing device	Touchpad
Processor code	SLBPE
Processor ARK ID	43560
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1/4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	36 bit

Weight and Dimensions

Depth	236 mm
Width	336 mm
Weight	2120 g
Height (front)	31 mm
