2. Starting near the hinges, use a nonmarking, nonconductive tool to release the edges of the bottom
cover from the computer (1).
3. Remove the bottom cover from the computer (2).
To replace the bottom cover, reverse the removal procedures.
Memory modules
To remove the memory modules, use this procedure and illustration.
Table
5-2 Memory module descriptions and part numbers
Description Spare part number
16 GB, DDR4-3200 L67710-001
8 GB, DDR4-3200 L46598-001
4 GB, DDR4-3200 L83673-001
Memory module cover (included in Bracket Kit) M08556-001
Before removing the memory, follow these steps:
34 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
