Table 1-1 Product components and their descriptions (continued)
Category Description
Camera, HD RGB 720p + IR (infrared)
Camera privacy cover
Supports WDR (Wide Dynamic Range)
Support for models without a camera
RJ-45 (network) jack No direct Ethernet support, available via accessories
The following support S4/S5 wake on LAN (via out of band) and S0/S0ix/S4/S5 MPAT (via out of band): HP
USB-C Mini Dock, HP USB-C/A Universal Dock G2, HP USB-C Dock G5, HP USB-C Dock G4 3, HP Thunderbolt
Dock G2, and HP USB-C Mini Dock.
Wireless Wireless Local Area Network (WLAN) (select products only)
Intel Wi-Fi 6 AX201 + Bluetooth® 5 (802.11ax 2 × 2) (non-vPro)
Intel Wi-Fi 6 AX201 + Bluetooth 5 (802.11ax 2 × 2) (vPro)
Compatible with Miracast® devices
Two WLAN antennas congured at top of panel
Supports HP Connection Optimizer (with data analytics)
UEFI Wi-Fi (Wireless imaging/image recovery/BitLocker unlock)
Intel BT audio ooad
Supports Static BIOS SAR for Intel modules
Supports HP Extended Range Wireless LAN
Supports HP LAN-Wireless Protection (WLAN/LAN/WWAN switching)
Near Field Communication (NFC) (select products only)
NXP NPC300 Near Field Communication Module
NFC antenna
WWAN (select products only)
Intel XMM™ 7360 LTE-Advanced (Cat 9)
Intel XMM 7560 LTE-Advanced Pro (Cat 16)
Four WWAN antennas (worldwide 5 band, 2 at top and 2 at bottom of WWAN panels)
WWAN cards are compatible with a programmable removable eSIM
Supports WWAN after market option
Ports HDMI v1.4b
Audio-out (headphone)/audio-in (microphone) combo jack
(2) USB 3.1 Gen 1 Type-C® with Thunderbolt™
USB 3.1 Gen 1 port
USB 3.1 Gen 1 charging port
AC Smart Pin adapter plug, 4.5 mm
3
