10. Lift the display assembly straight up from the base enclosure and remove it.
NOTE: For a hinge-up display assembly replacement, reverse these procedures to reinstall the
display assembly.
11. Remove the display bezel:
a. Remove the two rubber pads (1) that cover the display panel screws.
Component replacement procedures
133
