To start Refresh:
1. On the Start screen, point to the far-right upper or lower corner of the screen to display
the charms.
2. Click Settings.
3. Click Change PC settings in the bottom-right corner of the screen, and then select General
from the PC settings screen.
4. Under Refresh your PC without affecting your files, select Get started, and follow the
on-screen instructions.
Remove everything and reinstall Windows
Sometimes you want to perform detailed reformatting of your computer, or you want to remove
personal information before you give away or recycle your computer. The process described in this
section provides a speedy, simple way to return the computer to its original state. This option removes
all personal data, apps, and settings from your computer, and reinstalls Windows.
IMPORTANT: This option does not provide backups of your information. Before using this option,
back up any personal information you wish to retain.
You can initiate this option by using the f11 key or from the Start screen.
To use the f11 key:
1. Press f11 while the computer boots.
– or –
Press and hold f11 as you press the power button.
2. Select Troubleshoot from the boot options menu.
3. Select Reset your PC, and follow the on-screen instructions.
To use the Start screen:
1. On the Start screen, point to the far-right upper or lower corner of the screen to display
the charms.
2. Click Settings.
3. Click Change PC settings in the bottom-right corner of the screen, and then select General
from the PC settings screen.
4. Under Remove everything and reinstall Windows, select Get started, and follow the
on-screen instructions.
160 Chapter 7 Backup and recovery

Table of Contents

Other manuals for HP EliteBook 8570w

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP EliteBook 8570w and is the answer not in the manual?

HP EliteBook 8570w Specifications

General IconGeneral
Bus typeDMI
SteppingE1
Tjunction105 °C
Processor cache8 MB
Processor cores4
Processor modeli7-3820QM
System bus rate5 GT/s
Processor familyIntel High End Desktop Processors
Processor seriesIntel Core i7-3800 Mobile Series
Processor socketBGA 1224
Processor threads8
Processor codenameIvy Bridge
Processor frequency2.7 GHz
Processor cache typeSmart Cache
Processor lithography22 nm
Processor manufacturerIntel
Processor front side bus- MHz
PCI Express slots version3.0
Processor boost frequency3.7 GHz
Processor operating modes64-bit
ECC supported by processorNo
PCI Express configurations1x8, 1x16, 2x4, 2x8
Thermal Design Power (TDP)45 W
Number of processors supported1
CPU multiplier (bus/core ratio)27
Maximum number of PCI Express lanes16
Motherboard chipsetIntel® QM77 Express
Memory slots2x SO-DIMM
Internal memory8 GB
Memory clock speed1600 MHz
Internal memory typeDDR3-SDRAM
Maximum internal memory- GB
HDD speed7200 RPM
HDD interfaceSATA
Storage mediaHDD
Optical drive typeCD-RW/DVD Combo
Card reader integratedYes
Total storage capacity750 GB
Compatible memory cardsMMC, SD
Display diagonal15.6 \
Display resolution- pixels
LightScribe-
Graphics card familyIntel, NVIDIA
Intel segment taggingEnterprise
On-board graphics card ID0x166
Discrete graphics card modelNVIDIA® Quadro® K3000M
On-board graphics card modelIntel® HD Graphics 4000
On-board graphics card familyIntel® HD Graphics
On-board graphics card base frequency650 MHz
On-board graphics card dynamic frequency (max)1250 MHz
Audio systemSRS Premium PRO
Number of built-in speakers2
Cabling technology10/100/1000Base-T(X)
Networking featuresGigabit Ethernet
Networking standardsIEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates10, 100, 1000 Mbit/s
Charging port typeDC-in jack
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 3.2 Gen 1 (3.1 Gen 1) ports quantity0
Pointing deviceTouchpad
Operating system installedWindows 7 Professional
Form factorClamshell
Product colorBlack
Country of originChina
Battery life (max)- h
AC adapter power200 W
Sustainability certificatesEPEAT Gold, ENERGY STAR
Processor codeSR0MK
Processor ARK ID64889
Processor package size37.5 x 37.5 (rPGA988B); 31.0 x 24.0 (BGA1224) mm
Supported instruction setsAVX
Intel Identity Protection Technology version1.00
Weight and Dimensions IconWeight and Dimensions
Depth382 mm
Width345 mm
Height25.75 mm
Weight3000 g
