HP EliteBook 8570w User Manual

Speakers
Description Spare part number
Speaker kit 652669-001
Before removing the speakers, follow these steps:
IMPORTANT: Make special note of each screw and screw lock size and location during removal
and replacement.
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet,
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 54).
5. Remove the service door (see
Service door on page 60).
6. Remove the following components:
a. Hard drive (see
Hard drive on page 72).
b. Upgrade bay device (see
Upgrade bay device on page 77).
c. Keyboard (see
Keyboard on page 81).
d. Top cover (see
Top cover on page 87).
e. Audio/USB 3.0 board (see
Audio/USB 3.0 board on page 106).
Remove the speakers:
1. Position the computer right-side up, with the front toward you.
2. Remove the display latch:
a. Remove the spring (1) from the display latch lock.
b. Remove the three Phillips screws (2) from the display latch lock.
c. Push down the button (3) in the front right corner of the display latch lock.
110 Chapter 4 Removal and replacement procedures

HP EliteBook 8570w Specifications

General

Bus type	DMI
Stepping	E1
Tjunction	105 °C
Processor cache	8 MB
Processor cores	4
Processor model	i7-3820QM
System bus rate	5 GT/s
Processor family	Intel High End Desktop Processors
Processor series	Intel Core i7-3800 Mobile Series
Processor socket	BGA 1224
Processor threads	8
Processor codename	Ivy Bridge
Processor frequency	2.7 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x8, 1x16, 2x4, 2x8
Thermal Design Power (TDP)	45 W
Number of processors supported	1
CPU multiplier (bus/core ratio)	27
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel® QM77 Express
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	- GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	CD-RW/DVD Combo
Card reader integrated	Yes
Total storage capacity	750 GB
Compatible memory cards	MMC, SD
Display diagonal	15.6 \
Display resolution	- pixels
LightScribe	-
Graphics card family	Intel, NVIDIA
Intel segment tagging	Enterprise
On-board graphics card ID	0x166
Discrete graphics card model	NVIDIA® Quadro® K3000M
On-board graphics card model	Intel® HD Graphics 4000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1250 MHz
Audio system	SRS Premium PRO
Number of built-in speakers	2
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 3.2 Gen 1 (3.1 Gen 1) ports quantity	0
Pointing device	Touchpad
Operating system installed	Windows 7 Professional
Form factor	Clamshell
Product color	Black
Country of origin	China
Battery life (max)	- h
AC adapter power	200 W
Sustainability certificates	EPEAT Gold, ENERGY STAR
Processor code	SR0MK
Processor ARK ID	64889
Processor package size	37.5 x 37.5 (rPGA988B); 31.0 x 24.0 (BGA1224) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	382 mm
Width	345 mm
Height	25.75 mm
Weight	3000 g
