HP EliteBook 8570w

For use in country/region Spare part
number
For use in country/region Spare part
number
For use in Japan 690648-291 For use in the United Kingdom
and Singapore
690648-031
For use in Latin America 690648-161 For use in the United States 690648-001
Before removing the keyboard, follow these steps:
IMPORTANT: Make special note of each screw and screw lock size and location during removal
and replacement.
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet,
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 54).
5. Remove the service door (see
Service door on page 60).
6. Remove the Upgrade bay device (see
Upgrade bay device on page 77)
Remove the keyboard:
1. Turn the computer upside down, with the front toward you.
2. Loosen the three Phillips captive spring-loaded screws that secure the keyboard to the computer.
3. Open the computer and turn it on its side.
Component replacement procedures
83
