For use in country/region Spare part

number

For use in country/region Spare part

number

For use in Japan 703151-291 For use in the United Kingdom

and Singapore

703151-031

For use in Latin America 703151-161 For use in the United States 703151-001

Keyboard with backlight for use only on computer models

equipped with the Windows 7 operating system (includes

backlight cable):

For use in the Netherlands 690647-B31

For use in Belgium 690647-A41 For use in Norway 690647-091

For use in the Canada 690647-DB1 For use in Russia 690647-251

For use in the Czech Republic

and Slovakia

690647-FL1 For use in South Korea 690647-AD1

For use in Denmark 690647-081 For use in Sweden and Finland 690647-B71

For use in France 690647-051 For use in Switzerland 690647-BG1

For use in Germany 690647-041 For use in Taiwan 690647-AB1

For use in India 690647-D61 For use in Thailand 690647-281

For use in Italy 690647-061 For use in the United Kingdom

and Singapore

690647-031

For use in Latin America 690647-161 For use in the United States 690647-001

Keyboard without backlight for use only on computer models

equipped with the Windows 7 operating system:

For use in the Netherlands 690648-B31

For use in Belgium 690648-A41 For use in Norway 690648-091

For use in Brazil 690648-201 For use in Northwest Africa 690648-FP1

For use in Bulgaria 690648-261 For use in Portugal 690648-131

For use in Canada 690648-DB1 For use in Romania 690648-271

For use in the Czech Republic

and Slovakia

690648-FL1 For use in Russia 690648-251

For use in Denmark 690648-081 For use in Saudi Arabia 690648-171

For use in France 690648-051 For use in Slovenia 690648-BA1

For use in Germany 690648-041 For use in South Korea 690648-AD1

For use in Greece 690648-151 For use in Spain 690648-071

For use in Hungary 690648-211 For use in Sweden and Finland 690648-B71

For use in Iceland 690648-DD1 For use in Switzerland 690648-BG1

For use in India 690648-D61 For use in Taiwan 690648-AB1

For use in Israel 690648-BB1 For use in Thailand 690648-281

For use in Italy 690648-061 For use in Turkey 690648-141

82 Chapter 4 Removal and replacement procedures
