Spare part
number
Description
690628-001 Fan and heat sink assembly for use in computers with AMD FirePro M4000 graphics cards
690629-001 Fan and heat sink assembly for use in computers with NVIDIA Quadro K1000M graphics cards
690630-001 Fan and heat sink assembly for use in computers with NVIDIA Quadro K2000M graphics cards
690631-001 Integrated fingerprint reader
690632-001 Raw Panel Support Kit
690633-001 Battery Latch Kit
690634-001 Power button board
690635-001 Function button board
690636-001 Audio/USB 3.0 board
690637-001 NVIDIA Quadro K2000M (NVIDIA N14P-Q3 2GB DDR3) graphics card
690638-001 NVIDIA Quadro K1000M (NVIDIA N14P-Q1 2GB DDR3) graphics card
690639-001 AMD FirePro M4000 (Chelsea XT GL 1GB GDDR5) graphics card
690640-001 VGA (Dsub 15-pin) port
690641-001 I/O board
690642-001 System board (includes replacement thermal material and VGA support bracket) for use with dual-core
processors and the Windows 7 operating system in all countries except China and Russia
690642-501 System board (includes replacement thermal material and VGA support bracket) for use with dual-core
processors and the Windows 8 Standard operating system in all countries except China and Russia
690642-601 System board (includes replacement thermal material and VGA support bracket) for use with dual-core
processors and the Windows 8 Professional operating system in all countries except China and Russia
690643-001 System board (includes replacement thermal material and VGA support bracket) for use with quad-core
processors and the Windows 7 operating system in all countries except China and Russia
690643-501 System board (includes replacement thermal material and VGA support bracket) for use with quad-core
processors and the Windows 8 Standard operating system in all countries except China and Russia
690643-601 System board (includes replacement thermal material and VGA support bracket) for use with quad-core
processors and the Windows 8 Professional operating system in all countries except China and Russia
690644-001 39.6 cm (15.6 in) High-Definition Plus (HD+) AntiGlare (AG) LED WVA
690645-001 Top cover (includes TouchPad button and bracket)
690647-001 Full-size backlit keyboard with separate numeric keypad and TouchPad scroll zone for use only on computer
models equipped with the Windows 7 operating system in the United States
690647-031 Full-size backlit keyboard with separate numeric keypad and TouchPad scroll zone for use only on computer
models equipped with the Windows 7 operating system in the United Kingdom and Singapore
690647-041 Full-size backlit keyboard with separate numeric keypad and TouchPad scroll zone for use only on computer
models equipped with the Windows 7 operating system in Germany
690647-051 Full-size backlit keyboard with separate numeric keypad and TouchPad scroll zone for use only on computer
models equipped with the Windows 7 operating system in France
40 Chapter 3 Illustrated parts catalog
