Item Description Spare part number
(19) Audio/USB 2.0 board 689284-001
(20) Display (VGA) port 696435-001
(21) Power connector cable
NOTE: The power connector cable is included in the Cable Kit, spare part number 652545-001.
(22) Modem cable 628824-001
(23) Network cable (includes RJ-45 jack)
NOTE: The network cable is included in the Cable Kit, spare part number 652545-001.
652545-001
(24) USB 3.0 board 689283-001
(25) Battery:
9-cell, Li-ion, 2.2 Ah (73 WHr) 634089-001
9-cell, Li-ion, 3.0 Ah (100 WHr) 634087–001
8-cell, Li-ion, 2.8 Ah (75 WHr) 632425-001
8-cell, Li-ion, 2.8 Ah (83 WHr) 632427-001
(26) Base enclosure (includes computer feet) 688765-001
(27) ExpressCard (plastic insert) 655546-001
(28) Mass storage device
Supports 7.0 mm (0.28 in), 9.5 mm (0.37 in) or 12.7 mm (0.5 in) hard drives and 6.35 cm (2.5 in) solid-state drive for
primary and secondary storage:
NOTE: The hard drive bracket and screws are included in the Hard Drive Hardware Kit, spare part number
642774-001.
●
750 GB, SATA, 7200-rpm 633252-001
● 500 GB, SATA, 7200-rpm 634925-001
●
320 GB, SATA, 7200-rpm 634862-001
●
500 GB SATA SED (Self-Encrypting Drive), 7200-rpm 683801-001
(29) Optical drive (includes bezel and bracket) supported in upgrade bay
Blu-ray R/RE DVD±RW SuperMulti Double-Layer Drive 688772-001
Blu-ray ROM DVD±RW SuperMulti Double-Layer Drive 688771-001
DVD±RW SuperMulti Double-Layer Drive 688770-001
DVD-ROM Drive 688769-001
Also supported in upgrade bay:
500 GB, 7200 rpm hard drive 634925-001
(30) Service access cover 698410-001
699467-001 (RCTO)
(31) Smart Card reader (includes cable) 688742-001
28 Chapter 3 Illustrated parts catalog
