Component replacement procedures
This chapter provides removal and replacement procedures.
There are as many as 98 screws and screw locks that must be removed, replaced, or loosened when
servicing the computer. Make special note of each screw and screw lock size and location during
removal and replacement.
Service tag and PCID label
Service tag
When ordering parts or requesting information, provide the computer serial number and model
number provided on the service tag.
Item Component Description
(1) Product name This is the product name affixed to the front of the
computer.
(2) Serial number (s/n) This is an alphanumeric identifier that is unique to each
product.
(3) Part number/Product number (p/n) This number provides specific information about the
product’s hardware components. The part number helps
a service technician determine what components and
parts are needed.
(4) Warranty period This number describes the duration of the warranty
period for the computer.
PCID label
The PCID label provides the information required to properly reset the notebook firmware (BIOS)
back to factory shipped specifications when replacing the system board. The label may have a
different number of characters depending on the operating system on the computer.
NOTE: Computer details may vary from images.
Component replacement procedures 49
