Display panel cable
Description Spare part number
Display panel cable (select models only) 688761-001
To remove the display panel cable:
▲
Release the adhesive tape that secures the display panel cable to the display panel (1).
Disconnect the cable (2), and then remove the cable (3).
Hinge brackets
Description Spare part number
Display hinge brackets (consists of the hinge piece and the vertical support brackets for the left and
right sides)
652528-001
To remove the display panel hinge brackets:
Component replacement procedures 81
