Remove the webcam module:
1. Lift the WLAN antenna cables (1), and then remove the WWAN antenna cables (2).
2. Remove the webcam cable (1) from the hinges and then disconnect the webcam cable from the
display enclosure (2).
3. Remove the webcam module from the display enclosure (3).
Reverse this procedure to install the webcam module.
Top cover
Description Spare part number
Top cover (includes TouchPad) 688747-001
Component replacement procedures 83
