Keyboard
Description Spare part number
Keyboard (backlit; includes keyboard cable and backlight cable)
NOTE: For a detailed list of available keyboards, see
Sequential part number listing on page 22.
804214-xx1
Before removing the keyboard, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the bottom cover (see
Bottom cover on page 32).
5. Disconnect the battery cable.
Remove the keyboard:
1. Remove the Phillips PM2.0×2.8 broadhead screw (1) that secures the keyboard to the computer.
2. Disconnect the keyboard backlight cable from the system board (2).
38 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
