Installing a secondary 3.5-inch hard drive
1. Prepare the computer for disassembly (Preparation for disassembly on page 19).
2. Remove the access panel (Access panel on page 20).
3. Install four silver 6-32 mounting screws on the sides of the drive (two on each side).
NOTE: HP has supplied four extra silver 6-32 mounting screws installed on the chassis next to the
primary 3.5-inch hard drive bay. Refer to Installing and Removing Drives on page 32 for an illustration of
the location of the extra mounting screws.
When replacing a drive, transfer the four mounting screws from the old drive to the new drive.
4. Rotate the drive cage to its upright position.
40 Chapter 4 Removal and replacement procedures – small form factor (SFF) chassis
