CAUTION: Fan sink retaining screws should be tightened in diagonally opposite pairs (as in an X) to evenly
seat the fan sink on the processor to avoid damage that could require replacing the system board.
Failure to install the bae may cause the computer to overheat.
Processor
Description
AMD A10-8850B, 3.9 GHz
AMD A10-8750B, 3.6 GHz
AMD A10-7800B, 3.57 GHz
AMD A8-8650B, 3.2 GHz
AMD A8-7600B, 3.1 GHz
AMD A6-8550B, 3.7 GHz
AMD A6-8350B, 3.5 GHz
AMD A4-7300B, 3.8 GHz
1. Prepare the computer for disassembly (Preparation for disassembly on page 19).
2. Remove the access panel (Access panel on page 20).
3. Rotate the drive cage to its upright position.
4. Rotate the small bae into the upright position (Small bae on page 47).
5. Remove the fan bae (Fan bae on page 48).
6. Remove the heat sink (Fan sink on page 55).
7. Rotate the locking lever to its full open position (1).
56 Chapter 4 Removal and replacement procedures – small form factor (SFF) chassis
