Redundant Array of Independent Drives (RAID)
Flexible implementation:
DriveLock is supported while in RAID mode. Users can manage the DriveLock password from within F10 Setup. Locked drives will
be displayed as such in the RAID option ROM interface.
Hard drive information can be viewed within F10 Setup while in RAID mode. Previously, the hard drives will not appear in Drive
Configuration when switching to RAID mode.
DPS Self-Test can be executed on physical hard drives while in RAID mode.
The RAID Setup Utility (accessed through CTRL-I) can be protected by the F10 Setup password.
NOTE:
RAID 1 is the only RAID configuration offered via factory configurations. The pre-configured systems:
Are only available on the SFF and TWR form factors. The USDT and DM form factors do not support RAID as they do not allow for
multiple common storage drives.
Are complete RAID systems and have both drives installed. If the TWR is configured with three hard disk drives, the third drive is
would be un-partitioned and not part of the RAID array
Have the necessary Option ROM configuration.
Are pre-loaded and pre-installed with all required Intel software.
Include a preinstalled operating system that is mirrored mode out of the box.
HP 1TB 10K rpm SATA 6.0Gb/s 3.5" Hard Disk Drive
Capacity
1 TB
Rotational Speed
10,000 rpm
Interface
Serial ATA (6.0 Gb/s)
Synchronous Transfer Rate
(Maximum)
Up to 600 MB/s
Buffer Size
64 MB
Cache
Adaptive
Seek Time
(typical reads,
includes controller overhead,
including settling)
Single Track:
1.2 ms
Average:
3.6 ms
Full-Stroke:
9.0 ms
Height
(nominal)
0.6 in/1.53 mm
Width
(nominal)
Media diameter: 2.5 in/63.6 mm
Physical size: 2.75 in/69.9 mm
Operating Temperature
41° to 131° F (5° to 55° C)
QuickSpecs
HP EliteDesk 800 G1 Series Business Desktop
Technical Specifications – Hard Disk and Solid State Storage
DA - 14653 North America — Version 16 — December 12, 2013
Page 31
