HP EliteDesk 800 G1 series User Manual

Weights & Dimensions
(configured with 1 HDD & 1 ODD)
DM USDT SFF TWR
Chassis (W x H x D) 6.9 x 1.3 x 7.0 in
175 x 34 x 177 mm
9.9 x 2.6 x 10 in
251 x 66 x 254 mm
13.3 x 3.95 x 14.9 in
338 x 100 x 379 mm
6.7 x 15.7 x 17.4 in
170 x 399 x 442 mm
System Volume 62.79 cu in
1.05 L
257.5 cu in
4.2 L
782.7 cu in
12.8 L
1828 cu in
30 L
System Weight * 2.9 lb
1.3 kg
6.8 lb
3.1 kg
16.7 lb
7.6 kg
20.5 lb
9.3 kg
Max Supported Weight
(desktop orientation)
N/A 77.0 lb
35.0 kg
77.0 lb
35.0 kg
N/A
Tower Stand
(H x W x D)
Pending 1.1 x 4.9 x 6.7 in
27 x 125 x 170 mm
1.1 x 7.0 x 7.9 in
29 x 178 x 200 mm
N/A
Packaging
(H x W x D)
Pending 8.6 x 15.7 x 19.7 in
218 x 398 x 500 mm
9.0 x 19.7 x 23.4 in
229 x 500 x 594 mm
11.6 x 19.7 x 23.2 in
295 x 500 x 590 mm
Shipping Weight Pending 14.4 lb
6.5 kg
17.9 lb
8.1 kg
28.8 lb
13.1 kg
Palletization Profile Pending 6-units per layer
10-layer max.
60-units per pallet
4-units per layer
10-layer max.
40-units per pallet
4-units per layer
8-layer max.
32-units per pallet
QuickSpecs
HP EliteDesk 800 G1 Series Business Desktop
Technical Specifications – Weights & Dimensions
DA - 14653 North America — Version 16 — December 12, 2013 Page 61

HP EliteDesk 800 G1 series Specifications

General

Processor Options	Intel Core i3, i5, i7
Chipset	Intel Q87
Memory	Up to 32GB DDR3
Storage Options	HDD or SSD options available
Graphics	Integrated Intel HD Graphics or optional discrete graphics
Operating System	Windows 7, Windows 8, Windows 10
Form Factor	Ultra-Slim Desktop, Small Form Factor, Mini Tower
Audio	Integrated high-definition audio
Ports	USB 3.0, USB 2.0, DisplayPort, VGA, serial, PS/2, audio
Networking	Gigabit Ethernet
Expansion Slots	PCI, PCIe x1, PCIe x16
Power Supply	Varies by form factor
Dimensions	Varies by form factor
Weight	Varies by form factor
