HP EliteDesk 800 G1 Tower User Manual

No. System Board Connector System Board Label Color Component
15 Power PWR white System Board
16 USB 3.0 FRONT USB3.0 blue Front USB 3.0 Ports
17 USB 3.0 MEDIA3.0 black USB 3.0 Device, such as a USB 3.0
Media Card Reader
18 SATA 3.0 SATA0 dark blue Primary Hard Drive
19 SATA 3.0 SATA1 light blue Any SATA Device other than the
Primary Hard Drive
20 SATA 3.0 SATA2 light blue Any SATA Device other than the
Primary Hard Drive
21 USB 2.0 MEDIA black USB 2.0 Device, such as a USB 2.0
Media Card Reader
Drives
Description Spare part number
Optical drives
DVD±RW drive 657958-001
DVD-ROM drive 608394-001
Blu-ray BD-RW SuperMulti XL Drive 719157-001
Hard drives
2 TB, 7200 rpm hard drive 616608-001
1 TB hard drive, hybrid SSD, 2.5-inch hard drive 724937-001
1 TB, 10000 rpm hard drive 719106-001
1 TB, 7200 rpm hard drive 613202-001
750 GB, 7200 rpm, 2.5-inch hard drive, hybrid SSD, 2.5-inch hard drive 719105-001
500 GB, 10000 rpm hard drive 683923-001
500 GB, 7200 rpm hard drive, self-encrypting (SED) 696442-001
500 GB hard drive, hybrid SSD, 2.5-inch hard drive 724938-001
256 GB Solid State Drive (SSD), self-encrypting (SED) 680020-001
128 GB Solid State Drive (SSD) 665961-001
32 GB mSATA drive, 2.5-inch 686616-001
32 GB mSATA drive 719566-001
108 Chapter 6 Removal and replacement procedures: Small Form Factor (SFF)

HP EliteDesk 800 G1 Tower Specifications

General

Tcase	72.72 °C
Bus type	DMI
Stepping	C0
Processor cache	8 MB
Processor cores	4
Processor model	i7-4790
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-4700 Desktop series
Processor socket	LGA 1150 (Socket H3)
Processor threads	8
Processor codename	Haswell
Number of QPI links	0
Processor frequency	3.6 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	4 GHz
Processor operating modes	32-bit, 64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	84 W
Number of processors installed	1
Maximum number of PCI Express lanes	16
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Memory layout (slots x size)	1 x 4 GB
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD-ROM
Card reader integrated	-
Total storage capacity	500 GB
Intel segment tagging	Enterprise
Intel® Virtualization Technology (Intel® VT)	VT-d, VT-x
On-board graphics card	Yes
On-board graphics card ID	0x412
Discrete graphics card model	Not available
On-board graphics card model	Intel® HD Graphics 4600
On-board graphics card family	Intel® HD Graphics
Maximum on-board graphics card memory	1.024 GB
On-board graphics card base frequency	350 MHz
On-board graphics card DirectX version	11.1
On-board graphics card dynamic frequency (max)	1200 MHz
Number of displays supported (on-board graphics)	3
Recovery operating system	Windows 8.1 Pro
Operating system installed	Windows 7 Professional
Operating system architecture	64-bit
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	6
Chassis type	Micro Tower
Product color	Black
Country of origin	China
Product type	PC
Motherboard chipset	Intel® Q87
Scalability	1S
Processor code	SR1QF
Processor ARK ID	80806
Intel TSX-NI version	0.00
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal solution specification	PCG 2013D
Intel Identity Protection Technology version	1.00
Power supply	320 W
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	442 mm
Width	170 mm
Height	399 mm
Weight	9300 g
