HP EliteDesk 800 G1 Datasheet

4
HP EliteDesk 800 G1 and EliteOne 800 G1 Family
Series
EliteDesk
EliteDesk
EliteDesk
EliteOne
Model
Ultra-slim Desktop
Small Form Factor
Tower
All-in-One
Operating
systems
Pre-installed (availability varies by region):
Windows 8 Pro (64-bit)*
Windows 8 (64-bit)*
Windows 7 Ultimate (64-bit)**
Windows 7 Professional (32-bit)**
Windows 7 Professional (64-bit)**
Windows 7 Professional (32-bit) (available through downgrade rights from Windows 8 Pro)***
Windows 7 Professional (64-bit) (available through downgrade rights from Windows 8 Pro)***
Windows 7 Home Premium (32-bit)**
Windows 7 Home Premium (64-bit)**
Windows 7 Home Basic (32-bit)**, ǂ
FreeDOS 2.0
Novell SUSE Linux Enterprise Desktop 11
Processors
2
Intel® 4th Generation Core™ i5, i7 Processors
Chipset
Intel® 8 Series (Q87)
Intel® 8 Series (Q87)
Intel® 8 Series (Q87)
Intel® 8 Series (Q87)
Display
N/A
N/A
N/A
23" diagonal IPS widescreen WLED; projected
capacitive touch panel optional
Webcam
11
and
microphone
Webcam sold separately
Webcam sold separately
Webcam sold separately
Integrated 2 MP webcam and dual microphone
array
20
Memory
24
1600 MHz DDR3 SDRAM; (2)
SODIMM slots enabling up to
16GB, dual channel memory
support
25
1600 MHz DDR3 SDRAM; (4)
DIMM slots enabling up to
32GB, dual channel memory
support
25
1600 MHz DDR3 SDRAM; (4)
DIMM slots enabling up to
32GB, dual channel memory
support
25
1600 MHz DDR3 SDRAM; (2) SODIMM slots
enabling up to 16GB, dual channel memory
support
25
Internal
storage
26
Up to 500GB SATA hard drive; up to 500GB self-encrypting solid state drive; up to 160GB solid state
drive
Up to 1TB solid state hybrid drive
5
; up to 500GB
SATA hard drive; 500GB SATA self-encrypting
drive; 256GB self-encrypting solid state drive; up
to 160GB solid state drive
Removable
storage
Slim DVD-ROM drive
27
, Slim SuperMulti DVD drive
27
, Slim BDXL Blu-ray Writer drive
27, 28
SD Media Card Reader, Slim DVD-ROM drive
27
,
Slim SuperMulti DVD drive
27
, Slim BDXL Blu-ray
Writer drive
27, 28
Expansion slots
(1) MiniPCIe
(1) MXM 3.0 Type A – 35W
(1) mSATA
(2) PCI Express x1 (v2.0)
(1) PCI Express x 16 (v2.0
– wired as x4)
(1 )PCI Express x16 (v3.0)
(2) PCI Express x1 (v2.0)
(1) PCI Express x 16 (v2.0
– wired as x4)
(1 )PCI Express x16 (v3.0)
(1) Optional PCI (v2.3)
(1 )MiniPCIe half-length (used by wireless LAN
module)
(1) MXM 3.0 Type A – 35W
(1 ) mSATA
Graphics
Integrated Intel® HD Graphics;
Discrete AMD® Radeon HD
7650A 2GB DDR3 MXM
graphics optional
Integrated Intel® HD Graphics;
Discrete AMD Radeon HD
8350, 8490
30
, NVIDIA NVS 310,
315, graphics optional
Integrated Intel® HD Graphics;
Discrete AMD Radeon HD
8350, 8490
30
, NVIDIA NVS 310,
315, or NVIDIA GeForce GT630
graphics optional
Integrated Intel® HD Graphics; Discrete AMD®
Radeon HD 7650A 2GB DDR3 MXM graphics
optional
Audio
DTS Studio Sound™, Realtek ALC 221 Audio (all ports stereo), microphone and headphone jacks,
stereo audio line out and integrated speaker
DTS Studio Sound™, Realtek ALC 3228 Audio – 16
& 24-bit PCM, microphone and headphone jacks,
stereo audio line out and high performance
integrated stereo speakers
Communications
Integrated Intel® I217LM Gigabit Network Connection; optional wireless LAN card available
Integrated Intel® I217LM Gigabit Network
Connection; optional wireless LAN cards and Near
Field Communication (NFC) available
24
Ports and
connectors
Front:
(2 )USB 2.0 ports,
(2) USB 3.0 ports, microphone,
headphone,
Rear:
(4) USB 2.0 ports,
(2) USB 3.0 ports,
stereo audio out, line in, RJ-45
Ethernet, PS/2 mouse and
keyboard, VGA, (2) DisplayPort
with multi-stream
4
, power
connector
Front:
(2 )USB 2.0 ports,
(2) USB 3.0 ports, microphone,
headphone,
Rear:
(4) USB 2.0 ports,
(2) USB 3.0 ports,
stereo audio out, line in, RJ-45
Ethernet, PS/2 mouse and
keyboard, VGA, (2) DisplayPort
with multi-stream
4
, power
connector, RS-232 serial port
Front:
(2 )USB 2.0 ports,
(2) USB 3.0 ports, microphone,
headphone,
Rear:
(4) USB 2.0 ports,
(2) USB 3.0 ports,
stereo audio out, line in, RJ-45
Ethernet, PS/2 mouse and
keyboard, VGA, (2) DisplayPort
with multi-stream
4
, power
connector, RS-232 serial port
Side:
(2) USB 3.0 ports including 1 fast charging port,
microphone, headphone, SD media card reader
(optional)
Rear:
(4) USB 3.0 ports, stereo audio out, RJ-45
Ethernet, PS/2 mouse and keyboard, DisplayPort
with multi-stream
4
, power connector, RS-232
serial port
Input devices
PS/2 keyboard, USB keyboard, Wireless Keyboard and Mouse, USB CCID SmartCard keyboard, USB PS/2 Washable keyboard, PS/2 mouse, USB Optical mouse,
USB 1000dpi Laser mouse, USB PS/2 Washable Scroll mouse
Power
External Power Adapter
135W (w/integrated graphics)
180W (w/discrete graphics)
Active PFC, up to 87% efficient
Internal 240W Power Supply,
Active PFC, up to 94%
efficient
31
Internal 320W Power Supply,
Active PFC, up to 94%
efficient
31
Internal 200W Power Supply, Active PFC, up to
93% efficient
Software
(Windows OS only)
HP business PCs are shipped with a variety of software titles including HP Client Security’, CyberLink Media Suite, HP ePrint Driver
29
, HP PageLift, HP Support
Assistant
12
, PDF Complete, and Skype
11
. Buy Office.
Warranty and
services
3/3/3-year limited warranty, including telephone support 24/7; terms and conditions may vary by country and region; other HP Care Pack
Services available.
32
HP recommends Windows.

HP EliteDesk 800 G1 Specifications

General

Chipset	Intel Q87 Express
Networking	Integrated Intel I217LM Gigabit Network Connection
Dimensions	Varies by form factor
Weight	Varies by form factor
Processor	Intel Core i7, i5, or i3 (4th Generation)
RAM	Up to 32 GB DDR3
Storage	HDD or SSD, various capacities
Graphics	Intel HD Graphics 4600
Operating System	Windows 7
Form Factor	Mini Tower, Small Form Factor, Ultra Slim Desktop
Audio	Integrated High Definition Audio
Ports	USB 3.0, USB 2.0, DisplayPort, VGA, Audio jacks
Expansion Slots	PCIe x16, PCIe x1, PCI (varies by form factor)
Power Supply	Varies by form factor (e.g., 240W, 280W, 320W)
