Item Description Spare part number
(6) Bar code scanner module 744037-001
(7) Cable connector board 744034-001
Cable Kit, includes: 744031-001
(8a) Bar code scanner module cable
(8b) Cable connector board cable
(8c) Credit card reader board/left board cable
(8d) Credit card reader board/right board cable
Cable Retainer Kit (20 pieces) 745882-001
(9) Left-side credit card reader board 744027-001
(10) Right-side credit card reader board 744028-001
(11) Credit card reader (includes cable) 744026-001
(12) Battery connector board (includes cable) 744033-001
(13) System board (includes docking connector and USB port) 744032-001
(14) Rear cover 744029-001
Retail Jacket equipped with battery (not illustrated) 742441-001
Retail Jacket equipped with a battery bay space saver (not illustrated) 742442-001
Handle (not illustrated) 742439-001
Miscellaneous Rocker Button Mounting Kit (not illustrated) 744038-001
Rubber Kit for use only on the Retail Jacket (not illustrated) 742443-001
Screw Kit for use only on the Retail Jacket (not illustrated) 744035-001
14 Chapter 3 Illustrated parts catalog
