Battery
To remove the battery:
1. Prepare the computer for disassembly (see Preparing to disassemble the computer on page 37).
2. Remove the hand strap (see Hand strap on page 38).
3. Remove the rear cover (see Backplate on page 39).
4. Remove the display (see Display on page 40).
5. From the back of the computer, disconnect the battery cable from the system board.
6. From the front of the computer, remove the ve screws (1) that secure the battery, and then lift the
battery out of the computer (2).
To install the battery reverse the removal procedures.
44 Chapter 6 Removal and replacement procedures for the mobility head unit
