HP ENVY 14 User Manual

What's new?
Using Stardock software
Stardock software includes the following features:
● Stardock MyColors—Offers a customizable desktop theme that transforms the look and feel of
your basic Windows desktop. The new desktop includes custom icons, visual styles (Start button
and taskbar), and 3 corresponding wallpapers. To change back to the standard Windows theme,
open the Stardock MyColors program and select the standard Windows theme.
●
Stardock Fences—Organizes the icons on your desktop. When the custom theme has been
applied, all of the icons on the desktop are moved to a vertical column or “fence” in the lower left
corner of the screen, with the Recycle Bin at the top. To customize Fences or to access the
software Help, select Start > All Programs > Stardock. Click Fences, and then click
Fences.lnk.
Using ATI Eyefinity Multi-Display technology
Your computer supports the new ATI Eyefinity™ technology, which provides the following features:
●
Allows you to use up to 2 external displays, as long as one of the displays is connected to the
Mini DisplayPort on the computer
●
Provides a new display configuration by spanning the image across a group of external displays
into a single large surface (SLS)
Example display configuration for single large surface (SLS)
You can use 2 external displays and span the image across them as an SLS. The 2 external displays
are connected to the computer using the Mini DisplayPort and the HDMI port.
NOTE: Identical resolution is required between external displays to form an SLS. Displays with
different native resolutions can still form an SLS by using non-native resolutions.
Switching the screen image
Press the switch screen image action key to open a dialog box that shows the 4 configuration
choices, independent of the number of connected display devices.
●
Disconnect Projector mode—Turns off the external display and displays the image only on the
computer display.
●
Duplicate mode—Clones the computer display onto an external display that is connected to the
HDMI port or the Mini DisplayPort on the computer.
2 Chapter 1 Welcome ENWW

HP ENVY 14 Specifications

General

Bus type	DMI
Stepping	C2
Tjunction	105 °C
Processor cache	3 MB
Processor cores	2
System bus rate	2.5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-500 Mobile Series
Processor socket	BGA 956
Processor threads	4
Processor codename	Arrandale
Processing Die size	81 mm²
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	2.93 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	18
Maximum number of PCI Express lanes	16
Number of Processing Die Transistors	382 M
Motherboard chipset	Intel® HM55 Express
HDD speed	7200 RPM
HDD interface	SATA
Optical drive type	DVD Super Multi
Card reader integrated	Yes
Total storage capacity	500 GB
Compatible memory cards	MMC, SD
Display diagonal	14.5 \
Display resolution	1600 x 900 pixels
Native aspect ratio	16:9
Memory slots	2x SO-DIMM
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
Memory layout (slots x size)	2 x 2 GB
Discrete graphics card model	AMD Radeon HD 5650
Maximum graphics card memory	2.714 GB
On-board graphics card model	Intel® HD Graphics
On-board graphics card base frequency	500 MHz
On-board graphics card dynamic frequency (max)	766 MHz
Type	PC
Power supply type	AC
Wireless technology	Wi-Fi
Graphics card family	AMD
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Cabling technology	10/100/1000Base-T(X)
Networking features	Gigabit Ethernet
Operating system installed	Windows 7 Home Premium
Sustainability certificates	ENERGY STAR
AC adapter power	90 W
Number of battery cells	8
Charging port type	DC-in jack
USB 2.0 ports quantity	3
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	0
Cable lock slot type	Kensington
Product color	Black
Country of origin	China
Pointing device	Touchpad
Processor ARK ID	47341
Processor package size	rPGA 37.5x 37.5, BGA 34x28 mm
Graphics & IMC lithography	45 nm
Supported instruction sets	SSE4.1/4.2
Intel® Turbo Boost Technology	1.0
Physical Address Extension (PAE)	36 bit

Weight and Dimensions

Depth	237 mm
Width	356 mm
Weight	2380 g
Height (rear)	28.2 mm
Height (front)	27.7 mm
