Remove the front speakers:
1. Release the front speaker cables from the clips (1) and routing channel built into the TouchPad.
2. Remove the four Phillips PM2.5×6.2 screws (2) that secure the front speakers to the top cover.
3. Remove the front speakers (3).
NOTE: The front speakers includes four rubber isolators (4). These isolators are crucial to the
performance of the front speakers.
Reverse this procedure to install the front speakers.
Component replacement procedures 87
