Item Component Spare part
number
Equipped with an Intel Core i7-6700HQ 2.60-GHz (SC turbo up to 3.50-GHz) processor (1600-MHz FSB,
6.0-MB L3 cache, dual core, 45 W (cTDP to 35 W)), a graphics subsystem with UMA memory, and
the Window 10 operating system
835869-601
Equipped with an Intel Core i7-6700HQ 2.60-GHz (SC turbo up to 3.50-GHz) processor (1600-MHz FSB,
6.0-MB L3 cache, dual core, 45 W (cTDP to 35 W)), a graphics subsystem with UMA memory, and a non-
Window 10 operating system
835869-001
Equipped with an Intel Core i7-6500U 2.50-GHz (SC turbo up to 3.10-GHz) processor (1600-MHz FSB,
4.0-MB L3 cache, dual core, 15 W), a graphics subsystem with UMA memory, and the Window 10
operating system
841040-601
Equipped with an Intel Core i7-6500U 2.50-GHz (SC turbo up to 3.10-GHz) processor (1600-MHz FSB,
4.0-MB L3 cache, dual core, 15 W), a graphics subsystem with UMA memory, and a non-Window 10
operating system
841040-001
Equipped with an Intel Core i5-6200U 2.30-GHz (SC turbo up to 2.80-GHz) processor (1600-MHz FSB,
3.0-MB L3 cache, quad core, 15 W), a graphics subsystem with UMA memory, and the Window 10
operating system
838260-601
Equipped with an Intel Core i5-6200U 2.30-GHz (SC turbo up to 2.80-GHz) processor (1600-MHz FSB,
3.0-MB L3 cache, quad core, 15 W), a graphics subsystem with UMA memory, and a non-Window 10
operating system
838260-001
(9) WLAN module:
Intel Dual Band Wireless-AC 7265 802.11 ac 2×2 WiFi + Bluetooth 4.2 Combo Adapter (non-vPro) for
use only on computer models with model numbers 17-s100 through 17-s199
793840-005
Intel Dual Band Wireless-AC 3165 802.11 ac 1x1 WiFi + Bluetooth 4.0 Combo Adapter for use on all
computer models
806723-005
(10) Optical drive cable (included in the Cable Kit, spare part number 810928-001)
(11) USB/audio board (includes cable) 844489-001
USB/audio board cable (not illustrated) 844490-001
(12) Power button board (includes cable) 809310-001
(13) Memory modules (2; PC3L, 12800, 1600-MHz):
8 GB 693374-005
4 GB 691740-005
(14) Power connector cable 809295-001
(15) Heat sink (includes replacement thermal materials):
For use only on computer models equipped with graphic subsystems with dedicated video memory 806827-001
For use only on computer models equipped with a graphics subsystem with UMA memory and an
Intel Core i7-6700HQ processor
828817-001
For use only on computer models equipped with a graphics subsystem with UMA memory and an
Intel Core i7-6500U or Intel Core i5-6200U processor
806826-001
(16) Fan (includes cable) 806747-001
(17) RTC battery 811080-001
(18) Hard drive (does not include hard drive brackets or hard drive cable):
For use only on computer models with model numbers 17-s100 through 17-s199:
HP Condential
16 Chapter 3 Illustrated parts catalog
