HP Envy 17 Series User Manual

Item Component Spare part
number
1-TB, 7200-rpm, SATA, 9.5-mm 766644-005
For use on all computer models:
2-TB, 5400-rpm, SATA, 9.5-mm 801808-005
1-TB, 5400-rpm, SATA, 9.5-mm 778192-005
1-TB, 5400-rpm, 8-GB hybrid, 9.5-mm 731999-005
(19) Hard drive brackets (2; included in the Hard Drive Hardware Kit, spare part number 809296-001)
(20) DVD±RW Double-Layer SuperMulti Drive 809304-001
(21) Battery (4-cell, 41 WHr, 2.8-AHr, Li-ion) 800049-005
(22) Bottom cover 843589-001
Bottom cover hinge caps (not illustrated; includes left and right caps) 809312-001
Rubber Kit (not illustrated, includes bottom cover screw covers) 809314-001
HP Condential
Computer major components 17

HP Envy 17 Series Specifications

General

Display Size	17.3 inches
RAM	Up to 32 GB DDR4
Storage	Up to 1 TB SSD
Operating System	Windows 11 or Windows 10
Weight	6.02 lbs (2.73 kg)
Ports	USB-C, USB-A, HDMI, SD card reader, headphone/microphone combo
Wireless	Wi-Fi 6
