HP ENVY x2 Maintenance And Service Guide

Category Description
Wireless Integrated WLAN options by way of wireless module and dual antennas
Supports the following WLAN formats:
Intel Dual Band Wireless-AC 3160 802.11 ac 1x1 WiFi + BT 4.0 Combo Adapter_US
Intel Dual Band Wireless-AC 7265 802.11 ac 2x2 WiFi + BT 4.0 Combo Adapter (non vPRO)
Intel WiDi5.0 support
Compatible with Miracast-certified devices
External media card Micro Secure Digital (SD) Media Reader
Push-push insertion/removal
Support SD/SDHC/SDXC with UHS
Internal card One M.2 slot for WLAN
Ports Tablet:
Headphone/mic-in combo jack
DC-in port
Pogo-pin (9 PIN) docking connector (to thin keyboard cover or audio dock)
HDMI v1.4 supporting: up to 1920x1080 @ 60Hz
USB 3.0 (2)
Thin Keyboard Cover:
Pogo-pin (9 PIN) docking connector (to tablet)
Audio Dock:
Hot Plug / Unplug and auto detect for correct output to wide-aspect vs. standard aspect video
(auto adjust panel resolution to fit embedded panel and external monitor connected)
Keyboard/Touchpad Detachable Soft Keyboard Cover (Bluetooth wireless interface):
Full-sized, island style, thin cover backlit keyboard (1.5 mm travel distance) with image sensor clickpad
and 1500 mA polymer battery
Touchpad requirements:
Taps enabled as default
Clickpad with image sensor
Supports Windows 8 modern touchpad gestures
Multi-touch gestures enabled (Default on for 2-finger scroll and pinch)
Active stylus:
Support active stylus writing
Power requirements AC adapter:
45-W Smart PFC, non-slim, 26.5 mm, 19.5V
1 meter (3.3 ft) length power cord
Tablet battery:
3-cell, 50 WHr battery (4.45 Ah)
Operating system Tablet (Preinstalled):
2 Chapter 1 Product description

HP ENVY x2 Specifications

General

Stepping	C0
Processor cache	1 MB
Processor cores	2
System bus rate	- GT/s
Processor family	Intel Atom®
Processor series	Intel Atom Z2700 Series
Processor socket	FC-MB4760
Processor threads	4
Processor codename	Cloverview
Processor frequency	1.8 GHz
Processor cache type	L2
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
Processor operating modes	32-bit
ECC supported by processor	No
Thermal Design Power (TDP)	- W
Motherboard chipset	-
Internal memory	2 GB
Memory clock speed	533 MHz
Memory form factor	On-board
Internal memory type	DDR2-SDRAM
Memory layout (slots x size)	1 x 2 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
Card reader integrated	Yes
Total storage capacity	64 GB
Compatible memory cards	SD
Number of SSDs installed	1
Display surface	Matt
Display diagonal	11.6 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Discrete graphics card model	Not available
Audio system	Beats Audio
Front camera resolution (numeric)	8 MP
Data network	Not supported
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Operating system installed	Windows 8
Form factor	Convertible (Detachable)
Product type	Hybrid (2-in-1)
Product color	Silver
Housing material	Metal
Country of origin	China
Processor code	SR0Z4
Processor ARK ID	70105
Processor package size	14 x 14 mm
Battery life (max)	7 h
Number of battery cells	2+2
AC adapter power	20 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Sustainability certificates	RoHS, EPEAT Silver, ENERGY STAR

Weight and Dimensions

Depth	206 mm
Width	303 mm
Height	19 mm
Weight	1390 g
