HP ENVY x2 Maintenance And Service Guide

Pairing the keyboard base
If you did not pair your keyboard base during the initial tablet setup, you can pair your keyboard base through
Bluetooth settings.
IMPORTANT: Before you can use your keyboard base, you must pair the keyboard base with the tablet to
establish a connection.
1. Turn on the tablet (1) and keyboard base (1).
2. Adjust the tablet stand and connect the tablet to the keyboard base (2). See
Adjusting the tablet stand
on page 9 and Connecting the tablet to the keyboard base on page 28 for more information.
3.
Press the Pairing key
(f12) (3) on the keyboard base for 3 seconds or until the pairing light begins
to blink rapidly.
4. From the Start screen, swipe from the right edge of the TouchPad or touch screen to display the
charms, and then select Settings.
5. Select Change PC Settings, select PC and device, select Bluetooth, and then select HP Wireless
Bluetooth Backlight Keyboard.
6. Type the PIN code and press Enter. The pairing light will be solid white when the pairing is successful
and then the light will turn off.
TIP: If the pairing is not successful, repeat step 3 through 6.
NOTE: After the keyboard base has been paired with the tablet, it must be charged before using it for the
first time. The battery light on the keyboard base turns off when the keyboard base is completely charged.
See
Charging the keyboard base battery on page 14 for more information.
Charging the keyboard base battery
The keyboard base has an internal, rechargeable battery. When the keyboard base battery light is blinking
amber, there is less than 10% battery charge remaining in the keyboard base.
To charge the keyboard base battery:
1. Connect the tablet to AC power.
2. Connect the keyboard base to the tablet. The battery light turns off when the keyboard base is
completely charged.
14 Chapter 3 Using the keyboard base

HP ENVY x2 Specifications

General

Stepping	C0
Processor cache	1 MB
Processor cores	2
System bus rate	- GT/s
Processor family	Intel Atom®
Processor series	Intel Atom Z2700 Series
Processor socket	FC-MB4760
Processor threads	4
Processor codename	Cloverview
Processor frequency	1.8 GHz
Processor cache type	L2
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
Processor operating modes	32-bit
ECC supported by processor	No
Thermal Design Power (TDP)	- W
Motherboard chipset	-
Internal memory	2 GB
Memory clock speed	533 MHz
Memory form factor	On-board
Internal memory type	DDR2-SDRAM
Memory layout (slots x size)	1 x 2 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
Card reader integrated	Yes
Total storage capacity	64 GB
Compatible memory cards	SD
Number of SSDs installed	1
Display surface	Matt
Display diagonal	11.6 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Discrete graphics card model	Not available
Audio system	Beats Audio
Front camera resolution (numeric)	8 MP
Data network	Not supported
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Operating system installed	Windows 8
Form factor	Convertible (Detachable)
Product type	Hybrid (2-in-1)
Product color	Silver
Housing material	Metal
Country of origin	China
Processor code	SR0Z4
Processor ARK ID	70105
Processor package size	14 x 14 mm
Battery life (max)	7 h
Number of battery cells	2+2
AC adapter power	20 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Sustainability certificates	RoHS, EPEAT Silver, ENERGY STAR

Weight and Dimensions

Depth	206 mm
Width	303 mm
Height	19 mm
Weight	1390 g
