HP ENVY x2 Maintenance And Service Guide

Item Component Spare part number
(1) Recess cover 790022-001
(2) Rear cover (includes hinge, hinge cover, antenna, stand cover, recess cover, and screws) 783092-001
(3) Heat sink not spared
(4) Vibration board (includes cable) 783106-001
(5) Speaker Kit (includes left and right speakers) 783110-001
(6) Hard drive connector
(7) Hard drive insulator bracket
(8) WLAN module
Intel Dual Band Wireless-AC 3160 802.11 ac 1x1 WiFi + BT 4.0 Combo Adapter_US 756751-005
Intel Dual Band Wireless-AC 7265 802.11 ac 2x2 WiFi + BT 4.0 Combo Adapter (non vPRO) 784644-005
Hard Drive Hardware Kit, includes: 783097-001
(9) POGO board (includes cable) 783103-001
(10) Touch screen board (includes cable) 783105-001
(11) Hard drive
500-GB, 5400-rpm, hybrid with 16 GB SSD 762179-005
500-GB, 5400-rpm, hybrid with 8 GB SSD 775520-005
(12) Power button board (includes cable) 783101-001
(13) Webcam (includes cable) 783117-001
(14) Volume control board (includes cable) 783104-001
(15) Audio/SD board (includes cable) 783102-001
(16) Battery (3-cell, 50-WHr, 4.45-AH) 767069-006
(17) Display cable 783094-001
(18) System board (includes processor and thermal grease)
Non-Windows 8 models with an Intel Core M-5Y70 processor and 8 GB of system memory 783115-001
Windows 8 Standard models with an Intel Core M-5Y70 processor and 8 GB of system memory 783115-501
Non-Windows 8 models with an Intel Core M-5Y70 processor and 4 GB of system memory 783112-001
Windows 8 Standard models with an Intel Core M-5Y70 processor and 4 GB of system memory 783112-501
Non-Windows 8 models with an Intel Core M-5Y10 processor and 8 GB of system memory 783116-001
Windows 8 Standard models with an Intel Core M-5Y10 processor and 8 GB of system memory 783116-501
Non-Windows 8 models with an Intel Core M-5Y10 processor and 4 GB of system memory 783113-001
Windows 8 Standard models with an Intel Core M-5Y10 processor and 4 GB of system memory 783113-501
(19) WLAN antenna 783091-001
(20) Display frame not spared
(21) Power connector 783095-001
18 Chapter 4 Illustrated parts catalog

HP ENVY x2 Specifications

General

Stepping	C0
Processor cache	1 MB
Processor cores	2
System bus rate	- GT/s
Processor family	Intel Atom®
Processor series	Intel Atom Z2700 Series
Processor socket	FC-MB4760
Processor threads	4
Processor codename	Cloverview
Processor frequency	1.8 GHz
Processor cache type	L2
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
Processor operating modes	32-bit
ECC supported by processor	No
Thermal Design Power (TDP)	- W
Motherboard chipset	-
Internal memory	2 GB
Memory clock speed	533 MHz
Memory form factor	On-board
Internal memory type	DDR2-SDRAM
Memory layout (slots x size)	1 x 2 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
Card reader integrated	Yes
Total storage capacity	64 GB
Compatible memory cards	SD
Number of SSDs installed	1
Display surface	Matt
Display diagonal	11.6 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Discrete graphics card model	Not available
Audio system	Beats Audio
Front camera resolution (numeric)	8 MP
Data network	Not supported
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Charging port type	DC-in jack
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Operating system installed	Windows 8
Form factor	Convertible (Detachable)
Product type	Hybrid (2-in-1)
Product color	Silver
Housing material	Metal
Country of origin	China
Processor code	SR0Z4
Processor ARK ID	70105
Processor package size	14 x 14 mm
Battery life (max)	7 h
Number of battery cells	2+2
AC adapter power	20 W
AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Sustainability certificates	RoHS, EPEAT Silver, ENERGY STAR

Weight and Dimensions

Depth	206 mm
Width	303 mm
Height	19 mm
Weight	1390 g
