Illustrated parts catalog
Maintenance and Service Guide 3–5
Broadcom 4312G 802.11b/g WiFi Adapter for use in Afghanistan, Albania, Algeria, Andorra,
Angola, Antigua and Barbuda, Argentina, Armenia, Aruba, Australia, Austria, Azerbaijan, the
Bahamas, Bahrain, Bangladesh, Barbados, Belarus, Belgium, Belize, Benin, Bermuda,
Bhutan, Bolivia, Bosnia and Herzegovina, Botswana, Brazil, the British Virgin Islands,
Brunei, Bulgaria, Burkina Faso, Burundi, Cameroon, Cape Verde, the Central African
Republic, Chad, Chile, Colombia, Comoros, the Congo, Costa Rica, Croatia, Cyprus, the
Czech Republic, Denmark, Djibouti, Dominica, the Dominican Republic, East Timor,
Ecuador, Egypt, El Salvador, Equitorial Guinea, Eritrea, Estonia, Ethiopia, Fiji, Finland,
France, French Guiana, Gabon, Gambia, Georgia, Germany, Ghana, Gibraltar, Greece,
Grenada, Guadeloupe, Guatemala, Guinea, Guinea-Bissau, Guyana, Haiti, Honduras, Hong
Kong, Hungary, Iceland, India, Ireland, Israel, Italy, the Ivory Coast, Jamaica, Jordan,
Kazakhstan, Kenya, Kiribati, Kyrgyzstan, Laos, Latvia, Lebanon, Lesotho, Liberia,
Liechtenstein, Lithuania, Luxembourg, Macedonia, Madagascar, Malawi, Malaysia, the
Maldives, Mali, Malta, the Marshall Islands, Martinique, Mauritania, Mauritius, Mexico,
Micronesia, Monaco, Mongolia, Montenegro, Morocco, Mozambique, Namibia, Nauru,
Nepal, the Nether Antilles, the Netherlands, New Zealand, Nicaragua, Niger, Nigeria,
Norway, Oman, Pakistan, Palau, Panama, Papua New Guinea, Paraguay, the People's
Republic of China, Peru, the Philippines, Poland, Portugal, the Republic of Moldova,
Romania, Russia, Rwanda, Samoa, San Marino, Sao Tome and Principe, Saudi Arabia,
Senegal, Serbia and Montenegro, the Seychelles, Sierra Leone, Singapore, Slovakia,
Slovenia, the Solomon Islands, Somalia, South Africa, South Korea, Spain, Sri Lanka, St.
Kitts and Nevis, St. Lucia, St. Vincent and the Grenadines, Suriname, Swaziland, Sweden,
Switzerland, Taiwan, Tajikistan, Tanzania, Togo, Tonga, Trinidad and Tobago, Tunisia, Turkey,
Turkmenistan, Tuvalu, Uganda, Ukraine, the United Arab Emirates, the United Kingdom,
Uruguay, Uzbekistan, Vanuatu, Venezuela, Vietnam, Yemen, Zaire, Zambia, and Zimbabwe
582562-002
Realtek RTL8191SE 802.11b/g/n 1x1 WiFi Adapter 593533-001
12 Modem module (select models only) 510100-001
13 System board
HM55 discrete system board 595181-001
HM55 UMA system board 595182-001
HM55 HDMI discrete system board 595183-001
HM55 HDMI UMA system board 595184-001
HM55 1.1 discrete system board 608823-001
HM55 1.1 HDMI discrete system board 608824-001
14 Hard drive (includes Hard Drive Hardware Kit)
500 GB, 7200 rpm 603784-001
320 GB, 7200 rpm 603783-001
250 GB, 7200 rpm 605606-001
Hard Drive Hardware Kit (not illustrated, includes bracket and screws) 609493-001
15 Power connector (includes cable) 600719-001
16 USB board (includes cable) 600717-001
17 RJ-11 connector included in Cable Kit (see “Cable Kit” on page 3-11 for spare part
component information)
600853-001
18 Optical drive bracket (included with optical drive)
19 Battery
6-cell Li-lon, 2.20 Ah, 47 Wh 593553-001
6-cell Li-lon, 2.55 Ah, 55 Wh 593554-001
20 Optical drive (includes optical drive bezel and bracket)
Item Description Spare part number
