3–6 Maintenance and Service Guide
Illustrated parts catalog
DVD±RW and CD-RW SuperMulti Double-Layer Combo Drive with LightScribe 602542-001
Blu-ray ROM with LightScribe DVD±R/RW SuperMulti Double-Layer Drive 602543-001
21 Optical drive cable included in Cable Kit (see “Cable Kit” on page 3-11 for spare part
component information)
600853-001
Bluetooth® module (not shown) 537921-001
Bluetooth cable (not shown) 602538-001
22 Base enclosure
Without HDMI and modem 599088-001
With card reader and HDMI, without modem 599089-001
Rubber Kit (not illustrated, includes four rubber feet) 600849-001
Plastics Kit (see “Plastics Kit” on page 3-9 for spare part component information) 595200-001
23 Hard drive cover
24 Memory module compartment cover
Item Description Spare part number
To Next Page
