4. Remove the UPS battery modules.
HP UPS R/T3000
WARNING! To prevent personal injury from electric shock or damage to the equipment, remove
the battery lead labels, and verify that the ERM circuit breakers are in the Off position.
1. Remove the UPS front bezel.
2. Disconnect the battery leads.
3. Remove the UPS battery bracket.
4. Remove the UPS battery modules.
IMPORTANT: Do not pull the battery leads when removing or installing the batteries.
HP UPS R5000
1. Remove the UPS front bezel.
2. Disconnect the battery leads.
Overview 9
