HP Blade System Architecture
HP Blade System Architecture
Figure 2 shows the rear view of the enclosure.
Figure 2 Rear View of the Blade Enclosure
1 Midplane connector
2 Eight external network ports
3 Installation handle
4 Unit ID (UID) LED and Health LED
Server Blade Signal
Compute Enclosure
Interconnect Bay
Interconnect Bay Labels
NIC 1(embedded) 1 orange interconnect label
