A-2
Specifications
Specifications
Acoustic
Geraeuschemission LwA=54 dB am fiktiven Arbeitsplatz nach DIN 45635 T.19
Noise Emission LwA=54 dB at virtual workspace according to DIN 45635 T.19
Connectors
■ The 10/100 Mbps RJ-45 twisted-pair ports are compatible with the
IEEE 802.3u 100Base-TX and IEEE 802.3 Type 10Base-T standards.
■ The 1000 Mbps RJ-45 twisted-pair port on the 100/1000-T transceiver is
compatible with the IEEE 802.3ab standard.
■ The 100 Mbps SC fiber-optic port on the 100Base-FX Transceiver is
compatible with the IEEE 802.3u 100Base-FX standard.
■ The 1000 Mbps SC fiber-optic ports on the Gigabit-SX and Gigabit-LX
Transceivers are compatible with the IEEE 802.3z Gigabit-SX and
Gigabit-LX standards.
Safety
Complies with:
■ EN60950 / IEC 950
■ CSA 22.2 No. 950
■ NOM-019-SCFI-1994
■ UL 1950
2353-ed2.book Page 2 Friday, February 9, 2001 6:00 PM
