1-4
Introducing the Switch
Back of the Switch
Back of the Switch
Power Connector
The switches do not have a power switch. They are powered on when the
external AC/DC power adapter is connected to the switch and to a power
source. The external AC/DC power adapter supplies 12 volts DC to the switch
and automatically adjusts to any AC voltage between 100-240 volts and either
50 or 60 Hz. No voltage range settings are required.
54321
87654321
RJ-45 ports DC power connector
HP 1405-5 Switch (J9791A)
HP 1405-5G Switch (J9792A)
HP 1405-8 Switch (J9793A)
HP 1405-8G Switch (J9794A)
RJ-45 ports DC power connector
