2 Install the print server hardware
Set up the printer
NOTE: Do not install any printer software until all of the hardware connection steps have been
completed.
If the printer is already set up
1. Turn off the printer.
2. Detach it from any computer.
3. Turn on the printer.
4. Proceed to
Connect the print server to the printer on page 11.
If the printer is not already set up
1. Assemble the hardware only using the instructions supplied with the printer.
2. Set aside the printer CD. (Do not install its software yet. Do not attach the printer to your computer.)
3. Turn on the printer.
4. Print a test page as instructed.
Connect the print server to the printer
1. Connect the USB cable.
●
Plug the supplied USB cable into the USB connector on the back of the print server.
●
Plug the other end of the cable into the printer’s USB connector.
CAUTION: Do not use a USB hub, extender or parallel converter.
ENWW Set up the printer 11
